Ref. No. Part No. Part Name & Description Remarks
1 A51JXS064X PICTURE TUBE
EUR7717030 REMOTE CONTROL
JH291U-009 CONVERGENCE YOKE
K2JZ2B000021 ANTENNA PLUG
KDY3NKE65F DEFLECTION YOKE
2 L0AA12B00011 SPEAKER
3 TBM4G1125-1 MODEL NAME PLATE
4 TBM4G3003 PANASONIC BADGE
5 TBX4G89002 POWER BUTTON
6 TEK6935 DOOR SWITCH
TES4G206 COIL SPRING
THT4G1005R CRT SCREW
THT4G1010R SCREW (SPEAKER)
THT4G1013R SCREW
TKK4G8556 SPEAKER BRACKET
TKP4G11744 AC CORD BRACKET
7 TKP4G13087 DOOR
8 TKU4G9860-1 BACK COVER
9 TLK4G9079X DEGAUSSING COIL
TMM4G502 RUBBER WASHER
TMM4G503 RUBBER WEDGE
NLA TNP4G269CE A BOARD
NLA TNP4G276AR L BOARD
TPE4G14003 LAMI BAG
TPE4G14025 SET COVER
TQB4G3796 FAN BAG
TSM10032-4 PURITY MAGNET
TSN63115-4 PURITY MAGNET
TSX4G112L AC POWER CORD
10 TXFKY02CQ04 CABINET ASSY
TXFPC03CQ04 CARTON
TXFPD02AS03 CUSHION (BOTTOM)
TXFPD03BS07 CUSHION (TOP)
CAPACITORS
C001 ECEA1CKA220 E 22UF, 16V
C002 ECJ2VF1H103Z C 0.01UF, Z, 50V
C003 ECJ2VF1H103Z C 0.01UF, Z, 50V
C005 ECJ2VF1H104Z C 0.1UF, Z, 50V
C006 ECA1AM331B E 330UF, 10V
C008 ECEA1HKA010 E 1UF, 50V
C1101 ECJ2VF1H103Z C 0.01UF, Z, 50V
C1103 ECJ2VC1H331J C 330PF, J, 50V
C1104 ECA1CM101B E 100UF, 16V
C1105 ECJ2VF1H103Z C 0.01UF, Z, 50V
C1125 ECEA1CKA100 E 10UF, 16V
C1130 ECJ2VC1H560J C 56PF, J, 50V
C1131 ECA0JM221B E 220UF, 6.3V
C1132 ECJ2VC1H560J C 56PF, J, 50V
C1140 ECEA1CKA101 E 100UF, 16V
C1141 ECJ2VF1H104Z C 0.1UF, Z, 50V
C1142 ECJ2VF1H104Z C 0.1UF, Z, 50V
C191 ECUX1H104KBX C 0.1UF, K, 50V
C193 ECA1CM100B E 10UF, 16V
C2302 ECA1EM471B E 470UF, 25V
C2303 ECA1CM100B E 10UF, 16V
C2304 ECEA1HKN010 E 1UF, 50V
C2305 ECEA1HKN010 E 1UF, 50V
C2306 ECA1HM220B E 22UF, 50V
C2380 ECA1CM101B E 100UF, 16V
C2381 ECA1CM100B E 10UF, 16V
C3020 ECJ2VC1H561K C 560PF, K, 50V
C3021 ECA1CM471B E 470UF, 16V
C3037 ECJ2VF1C105Z C 1UF, Z, 16V
C3136 ECJ2VB1H103J C 0.01UF, 50V
C3137 ECJ2VB1H103J C 0.01UF, 50V
C3138 ECA1CM100B E 10UF, 16V
C3139 ECA1CM100B E 10UF, 16V
C3144 ECJ2VC1H561K C 560PF, K, 50V
C3151 ECJ2VF1C105Z C 1UF, Z, 16V
C3153 ECJ2VF1C105Z C 1UF, Z, 16V
C3155 ECJ2VF1C105Z C 1UF, Z, 16V
C3157 ECJ2VF1C105Z C 1UF, Z, 16V
Ref. No. Part No. Part Name & Description Remarks
C3173 ECJ2VF1C105Z C 1UF, Z, 16V
C3175 ECJ2VF1C105Z C 1UF, Z, 16V
C350 ECA1CM101B E 100UF, 16V
C354 ECJ2VC1H330J C 33PF , J , 50V
C355 ECJ2VC1H330J C 33PF , J , 50V
C356 ECJ2VC1H330J C 33PF , J , 50V
C359 ECQM4104KZ P 0.1UF, K,400V
C368 ECJ2VC1H122J C 1200PF, J, 50V
C370 ECKW3D102KBP C 1000PF, K, 2KV
C371 ECEA1CN100U E 10UF, 16V
C373 ECA2EM100B E 10UF, 250V
C377 ECA1CM101B E 100UF, 16V
C402 ECA1HM101B E 100UF, 50V
C403 ECA1HM220B E 22UF, 50V
C404 ECQB1103JF P 0.01UF, J,100V
C406 ECA1HHG221 E 220UF, 50V
C408 ECQB1274JF P 0.27UF, J,100V
C502 F1B2H821A025 C 820PF, 500V
C503 F1B2H821A025 C 820PF, 500V
C504 ECJ2VB1H681K C 680PF, K, 50V
C506 F1A2H1000002 C 10PF , 500V
C511 ECA1VM101B E 100UF, 35V
C513 ECKW3D331JBP C 330PF, J, 2KV
C514 F2A1E102A151 E 1000UF , 25V
C515 F1B2H331A025 330PF , 500V
C516 F2A1E102A151 E 1000UF , 25V
C519 F2A2C330A020 E 33UF , 60V
C520 ECA0JM221B E 220UF, 6.3V
C552 ECA2EM100B E 10UF, 250V
C555 F1B2H471A025 C 470PF, 500V
C558 ECA2CMR47B E 0.47UF, 160V
C559 ECWH16822JVB P 8200PF,J,1.6KV
C560 ECQM4223JZ P 0.022UF, J,400V
C561 ECKW3D681JBR C 680PF, J, 2KV
C562 ECKW3D821KBN C 820PF, K, 2KV
C563 F0C2E394A039 P 0.39UF, 250V
C565 ECQP1H183JZ P 0.018UF, J, 50V
C566 ECQM4472JZ P 4700PF, J,400V
C567 ECQM4103JZ P 0.01UF, J,400V
C568 ECWH16202JVB P 2000PF,J,1.6KV
C570 ECJ2VC1H330J C 33PF , J , 50V
C580 ECA1HM220B E 22UF, 50V
C581 ECQV1H105JM P 1UF, J, 50V
C601 ECEA1CKA101 E 100UF, 16V
C602 ECUX1H104KBX C 0.1UF, K, 50V
C603 ECJ2VB1H472K C 4700PF, K, 50V
C604 ECQV1H224JL P 0.22UF, J, 50V
C605 ECQV1H224JL P 0.22UF, J, 50V
C606 ECJ2VC1H222J C 2200PF, J, 50V
C607 ECEA1HKA010 E 1UF, 50V
C608 ECA1HM100B E 10UF, 50V
C609 ECUX1H104KBX C 0.1UF, K, 50V
C610 ECJ2VB1H103J C 0.01UF, 50V
C611 ECEA1HKAR22 E 0.22UF, 50V
C612 ECJ2VB1H472K C 4700PF, K, 50V
C613 ECJ2VB1H472K C 4700PF, K, 50V
C614 ECQV1H104JL P 0.1UF, J, 50V
C615 ECQV1H224JL P 0.22UF, J, 50V
C618 F1B1H681A130 C 680PF, 50V
C619 ECQV1H104JL P 0.1UF, J, 50V
C620 ECJ2VC1H470J C 47PF, J, 50V
C621 ECJ2ZF1C105Z C 1UF, Z, 16V
C622 ECJ2VF1H104Z C 0.1UF, Z, 50V
C623 ECJ2VC1H470J C 47PF, J, 50V
C625 ECEA0JN221U E 220UF , 6.3V
C628 ECJ2VF1H224Z C 0.22UF, Z, 50V
C631 ECJ2VB1H222K C 2200PF, K, 50V
C632 ECJ2VB1H392K C 3900PF, K, 50V
C633 ECJ2ZF1C105Z C 1UF, Z, 16V
C636 ECA1CM101B E 100UF, 16V
C640 ECA1CM100B E 10UF, 16V
C641 ECJ2VC1H100C C 10PF, C, 50V
8.2. Replacement Parts List
23
TC-21Z80PQ
