Ref. No. Part No. Part Name & Description Remarks
R553 ERJ6GEYJ223 M 22KOHM,J,1/10W
R555 ERQ14AJ2R0P F 2.0OHM, J,1/4W
R556 ER050CKF5603 M 560KOHM,F, 1/2W
R557 ER050CKF1473 M 147KOHM,F, 1/2W
R558 ERDS2TJ223 C 22KOHM,J, 1/4W
R559 ERQ1CJP1R8S F 1.8OHM,J, 1W
R560 ERG1SJ102E M 1KOHM,J, 1W
R563 ERJ6GEY0R00 M 0OHM,J,1/10W
R580 ERJ6GEYJ392 M 3.9KOHM,J,1/10W
R581 ERJ6GEYJ183 M 18KOHM,J,1/10W
R582 ERJ6GEYJ154 M 150KOHM,J,1/10W
R583 ERJ6GEYJ274 M 270KOHM,J,1/10W
R584 ERJ6GEYJ563 M 56KOHM,J,1/10W
R585 ERJ6GEYJ272 M 2.7KOHM,J,1/10W
R586 ERJ6GEYJ103 M 10KOHM,J,1/10W
R587 ERJ6GEYJ823 M 82KOHM,J,1/10W
R588 ERJ6GEYJ104 M 100KOHM,J,1/10W
R589 ERJ6GEYJ103 M 10KOHM,J,1/10W
R590 ERJ6GEYJ333 M 33KOHM,J,1/10W
R591 ERJ6GEYJ103 M 10KOHM,J,1/10W
R592 ERJ6GEYJ222 M 2.2KOHM,J,1/10W
R593 ERJ6GEYJ103 M 10KOHM,J,1/10W
R594 ERJ6GEYJ104 M 100KOHM,J,1/10W
R601 ERJ6GEYJ153 M 15KOHM,J,1/10W
R603 ERJ6GEYJ393 M 39KOHM,J,1/10W
R604 ERJ6GEYJ101 M 100OHM,J,1/10W
R605 ERJ6GEYJ101 M 100OHM,J,1/10W
R606 ERJ6GEYJ101 M 100OHM,J,1/10W
R607 ERJ6GEYJ102 M 1KOHM,J,1/10W
R608 ERJ6GEYJ103 M 10KOHM,J,1/10W
R609 ERJ6GEYJ153 M 15KOHM,J,1/10W
R612 ERJ6GEYJ102 M 1KOHM,J,1/10W
R614 ERJ6GEYJ392 M 3.9KOHM,J,1/10W
R617 ERJ6GEYJ391 M 390OHM,J,1/10W
R619 ERJ6GEYJ121 M 120OHM,J,1/10W
R620 ERJ6GEYJ121 M 120OHM,J,1/10W
R623 ERJ6GEYJ331 M 330OHM,J,1/10W
R633 ERJ6GEYJ470 M 47OHM,J,1/10W
R634 ERJ6GEYJ750 M 75OHM, 1/10W
R640 ERJ6GEYJ822 M 8.2KOHM,J,1/10W
R672 ERJ6GEYJ181 M 180OHM,J,1/10W
R686 ERJ6GEYJ470 M 47OHM,J,1/10W
R687 ERJ6GEYJ472 M 4.7KOHM,J,1/10W
R688 ERJ6GEYJ103 M 10KOHM,J,1/10W
R689 ERJ6GEYJ750 M 75OHM, 1/10W
R801 ERF7ZK2R2 W 2.2OHM, 7W
R810 ERG2FJ470 M 47OHM,J, 2W
R811 ERG2FJ104H M 100KOHM,J, 2W
R817 ERDS1TJ100 C 10OHM,J, 1/2W
R818 ERG2FJ683H M 68KOHM,J, 2W
R820 ERX12SJR27E M 0.27OHM,J, 1/2W
R821 ERX12SJR27E M 0.27OHM,J, 1/2W
R824 ERDS2TJ152 C 1.5KOHM,J, 1/4W
R825 ERDS2TJ102 C 1KOHM,J, 1/4W
R830 ERDS2TJ101 C 100OHM,J, 1/4W
R831 ER0S2CKF1102 M 11KOHM,F, 1/4W
R832 ERDS2TJ473 C 47KOHM,J, 1/4W
R840 ERD75TAJ825 C 8.2MOHM,J, 3/4W
R850 ERG3SJ470 M 470OHM , J , 3W
R852 ERDS2TJ272 C 2.7KOHM,J, 1/4W
R854 TSF19402 FUSE
R861 ERDS1TJ221 C 220OHM,J, 1/2W
R864 ERJ6GEYJ103 M 10KOHM,J,1/10W
R866 ERJ6GEYJ472 M 4.7KOHM,J,1/10W
R867 D0AE362JA046 C 3.6KOHM , J , 1/4W
R868 ERDS1TJ471 C 470OHM,J, 1/2W
R871 ERDS1TJ103 C 10KOHM,J, 1/2W
R872 ERJ6GEYJ272 M 2.7KOHM,J,1/10W
R873 ERJ6GEYJ472 M 4.7KOHM,J,1/10W
R875 ERJ6GEYJ103 M 10KOHM,J,1/10W
TRANSFORMERS
T501 ZTFN82001A FLYBACK TRANS
T553 ETH19Y210AZ H DRIVE TRANS
T801 ETS29AV136AD SWITCHING TRANS
Ref. No. Part No. Part Name & Description Remarks
OTHERS
A12 TJSF29204 CONNECTOR
A22 TJS3A9650 4P CONNECTOR
A5 TJS3A9670 6P CONNECTOR
A8 TJS3A9670 6P CONNECTOR
L5 TJS3A9670 6P CONNECTOR
L8 TJS3A9670 6P CONNECTOR
L10 K1ZZ00001205 CONNECTOR
JA1 ERJ6GEY0R00 M 0OHM,J,1/10W
JA10 ERJ6GEY0R00 M 0OHM,J,1/10W
JA11 ERJ6GEY0R00 M 0OHM,J,1/10W
JA12 ERJ6GEY0R00 M 0OHM,J,1/10W
JA14 ERJ6GEY0R00 M 0OHM,J,1/10W
JA16 ERJ6GEY0R00 M 0OHM,J,1/10W
JA17 ERJ6GEY0R00 M 0OHM,J,1/10W
JA19 ERJ6GEY0R00 M 0OHM,J,1/10W
JA20 ERJ6GEY0R00 M 0OHM,J,1/10W
JA22 ERJ6GEY0R00 M 0OHM,J,1/10W
JA23 ERJ6GEY0R00 M 0OHM,J,1/10W
JA25 ERJ6GEY0R00 M 0OHM,J,1/10W
JA28 ERJ6GEY0R00 M 0OHM,J,1/10W
JA29 ERJ6GEY0R00 M 0OHM,J,1/10W
JA3 ERJ6GEY0R00 M 0OHM,J,1/10W
JA30 ERJ6GEY0R00 M 0OHM,J,1/10W
JA31 ERJ6GEY0R00 M 0OHM,J,1/10W
JA32 ERJ6GEY0R00 M 0OHM,J,1/10W
JA36 ERJ6GEY0R00 M 0OHM,J,1/10W
JA4 ERJ6GEY0R00 M 0OHM,J,1/10W
JA5 ERJ6GEY0R00 M 0OHM,J,1/10W
JA6 ERJ6GEY0R00 M 0OHM,J,1/10W
JA7 ERJ6GEY0R00 M 0OHM,J,1/10W
JA8 ERJ6GEY0R00 M 0OHM,J,1/10W
JA9 ERJ6GEY0R00 M 0OHM,J,1/10W
JK3002 K4BK06B00014 REAR AV TERMINAL
JK3102 K4BC11B00003 AV TERMINAL
JK351 330550044K2F CRT SOCKET
JS102 ERJ6GEY0R00 M 0OHM,J,1/10W
JS117 ERJ6GEY0R00 M 0OHM,J,1/10W
JS122 ERJ6GEY0R00 M 0OHM,J,1/10W
JS185 ERJ6GEY0R00 M 0OHM,J,1/10W
JS2310 ERJ6GEY0R00 M 0OHM,J,1/10W
JS2311 ERJ6GEY0R00 M 0OHM,J,1/10W
JS3120 ERJ6GEY0R00 M 0OHM,J,1/10W
JS3141 ERJ6GEY0R00 M 0OHM,J,1/10W
JS610 ERJ6GEY0R00 M 0OHM,J,1/10W
JS670 ECJ2VF1H223Z C 0.022UF, Z, 50V
JS671 ECJ2VF1H223Z C 0.022UF, Z, 50V
JS672 ECJ2VF1H223Z C 0.022UF, Z, 50V
JS680 ERJ6GEY0R00 M 0OHM,J,1/10W
JS891 ERJ6GEY0R00 M 0OHM,J,1/10W
F801 XBA2C40TR0 FUSE 250V 4A
S1001 EVQ11G05R SWITCH
S1002 EVQ11G05R SWITCH
S1003 EVQ11G05R SWITCH
S1004 EVQ11G05R SWITCH
S1005 EVQ11G05R SWITCH
S1006 EVQ11G05R SWITCH
S801 ESB92DA1B SWITCH
TNR001 ENV56K10G3F TUNER
X101 M1971M SAW FILTER
X181 EFCS4R5MW5 CERAMIC FILTER
X601 H0D120500006 CRYSTAL OSC
