Panasonic TH-103PF9UK - Rear Cover Removal

Zone Board
A
SC, DR1/2,,SU, SM, SD
C1, CZ, FAN
B PB, DS, HX, HA, DN,
HDD, CD, C3
D D, CD×2, Ｃ4
C P, CX
E P, F, C9
F SS, SS2, SS3, DR1/2
C6, C7, FAN
B＋C FAN, CD
D＋E FAN, CD, PC
A＋B C2
D＋F C5
A＋C CY, SC2
E＋F C8
Back Covers
The unit contains 6 back covers that provide access to
different areas of the board assembly.
