Board Description
Board Name Function Board Name Function
D Digital Signal Processor, Format Converter, Plasma
AI Processor Sub-Field Processor
CX Data Drive (X)
CY Data Drive (Y)
CZ Data Drive (Z)
H5 Audio Out
DS Slot Interface (Audio / Video / Sync Input Switch),
SYNC Processor, Audio Processor, Speaker Out
Amplifier, DC-DC Converter
S1 Power Switch
SS2 Sustain Out (Upper)
SS3 Sustain Out (Lower)
V1 LED_G, R
SS Sustain Drive V2 Key Scan
SC Scan Drive V3 Remote control Receiver
SC2 DC-DC Converter For Scan Drive PB Fan Control
SU Scan Out (Upper) P(SUS_1/2) Power Supply
SM Scan Out (Middle) P(MULTI_1/2) Power Supply
SD Scan Out (Lower) F Line Filter
C1 Data Drive (1) PC Power Control
C2 Data Drive (2) HX PC / RS-232C
C3 Data Drive (3) HA BNC Component Video
C4 Data Drive (4) DN Digital Signal Processor, Micon
C5 Data Drive (5) HDD DVI-D Terminal
C6 Data Drive (6) CD C Board / D Board Connection
C7 Data Drive (7) DR1 Energy Data Recovery
C8 Data Drive (8) DR2 Energy Data Recovery
C9 Data Drive (9)
9
