41
PC input signals
1:
Based on SMPTE 274M standard.
2: Based on SMPTE RP211 standard.
3: Based on SMPTE 295M standard.
4:
When selected the RGB format and 525p signal input to the Mini D-sub 15P terminal, it is recognized as VGA 60Hz signal.
5:
When inputted VGA 60Hz format signal from the other than Mini D-sub 15P terminal, it is recognized as 525p signal.
Note: Signals without above specifi cation may not be displayed properly.
Applicable input signals for Mini D-sub 15P (Component) / Mini D-sub 15P (RGB) (*
Mark)
Signal name
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Dot clock
frequency
(MHz)
Mini D-sub 15P
(Component)
Mini D-sub 15P
(RGB)
1 525 (480) / 60i 15.73 59.94 13.5
**
2 525 (480) / 60p 31.47 59.94 27.0
**
4
3 625 (575) / 50i 15.63 50.00 13.5
**
4 625 (575) / 50p 31.25 50.00 27.0
**
5 750 (720) / 60p 45.00 60.00 74.25
**
6 750 (720) / 50p 37.50 50.00 74.25
**
7 1,125 (1,080) / 60p 67.50 60.00 148.5
**
1
8 1,125 (1,080) / 60i 33.75 60.00 74.25
**
1
9 1,125 (1,080) / 50p 56.26 50.00 148.5
**
1
10 1,125 (1,080) / 50i 28.13 50.00 74.25
**
1
11 1,125 (1,080) / 24sF 27.00 47.92 74.25
**
2
12 1,125 (1,080) / 30p 33.75 30.00 74.25
**
1
13 1,125 (1,080) / 25p 28.13 25.00 74.25
**
1
14 1,125 (1,080) / 24p 27.00 24.00 74.25
**
1
15 1,250 (1,080) / 50i 31.25 50.00 74.25
**
3
16 640 × 400 @70 Hz 31.46 70.07 25.17
*
17 640 × 480 @60 Hz 31.47 59.94 25.18
*
5
18 640 × 480 @72 Hz 37.86 72.81 31.5
*
19 640 × 480 @75 Hz 37.50 75.00 31.5
*
20 640 × 480 @85 Hz 43.27 85.01 36.0
*
21 852 × 480 @60 Hz 31.47 59.94 33.54
*
5
22 800 × 600 @56 Hz 35.16 56.25 36.0
*
23 800 × 600 @60 Hz 37.88 60.32 40.0
*
24 800 × 600 @72 Hz 48.08 72.19 50.0
*
25 800 × 600 @75 Hz 46.88 75.00 49.5
*
26 800 × 600 @85 Hz 53.67 85.06 56.25
*
27 1,024 × 768 @60 Hz 48.36 60.00 65.0
*
28 1,024 × 768 @70 Hz 56.48 70.07 75.0
*
29 1,024 × 768 @75 Hz 60.02 75.03 78.75
*
30 1,024 × 768 @85 Hz 68.68 85.00 94.5
*
31 1,152 × 864 @75 Hz 67.50 75.00 108.0
*
32 1,280 × 768 @60 Hz 47.70 60.00 80.14
*
33 1,280 × 960 @60 Hz 60.00 60.00 108.0
*
34 1,280 × 960 @85 Hz 85.94 85.00 148.5
*
35 1,280 × 1,024 @60 Hz 63.98 60.02 108.0
*
36 1,280 × 1,024 @75 Hz 79.98 75.03 135.0
*
37 1,280 × 1,024 @85 Hz 91.15 85.02 157.5
*
38 1,600 × 1,200 @60 Hz 75.00 60.00 162.0
*
39 1,600 × 1,200 @65 Hz 81.25 65.00 175.5
*
40 1,066 × 600 @60 Hz 37.64 59.94 53.0
*
41 1,366 × 768 @60 Hz 48.36 60.00 86.71
*
42 Macintosh13” (640 × 480) 35.00 66.67 30.24
*
43 Macintosh16” (832 × 624) 49.72 74.54 57.28
*
44 Macintosh21” (1,152 × 870) 68.68 75.06 100.0
*
