3 Service Navigation
3.1. Important Notice
3.1.1. Model Name Identification
1. Model number is indicated the previous model number and space with A name plate as shown in figure.
2. TH-42PV8D/H/HM/M/MR/MS/MT will be discontinued and TH-42PV8DA/HA/HMA/M/AMRA/MSA/MTA will be introduced from
Aug/2008.
3.2. Different P.C.B.
Parts No. Parts name & Description Remarks
TH-42PV8D/H/HM/M/MR/MS/
MT
TH-42PV8DA/HA/HMA/MA/
MRA/MSA/MTA
TZTNP01RWTM TZTNP01BUUM CIRCUIT BOARD A PAVCSG DA/HA/HMA/MA/
MRA/MTA
TZTNP01RWTQ TZTNP01BUUQ CIRCUIT BOARD A PAVCSG MSA
TXNGS1RWTM CIRCUIT BOARD GS PAVCSG
LSEP1260MTHB LSEP1260WTHB CIRCUIT BOARD P PAVCSG DA/HA/HMA/MTA
LSEP1260MMHB LSEP1260WMHB CIRCUIT BOARD P PAVCSG MA/MRA/MSA
TXNC11RRTM TXNC11BDUM CIRCUIT BOARD C1 PAVCSG
TXNC21RRTM TXNC21BDUM CIRCUIT BOARD C2 PAVCSG
TXNSC1RRTM TXNSC1BDUM CIRCUIT BOARD SC PAVCSG
TXNSD1RRTM CIRCUIT BOARD SD PAVCSG
TXNSS1RRTM TXNSS1BDUM CIRCUIT BOARD SS PAVCSG
TXNSU1RRTM CIRCUIT BOARD SU PAVCSG
TXN/G1RRTM CIRCUIT BOARD G PAVCSG
TXN/K1RWTM CIRCUIT BOARD K PAVCSG
TXN/S1RRTM CIRCUIT BOARD S PAVCSG
