Panasonic TH-42PZ80U

108
13.2.2. Electrical Replacement Parts List
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
A1 K1KA09A00220 9P CONNECTOR 1
A3 K1KA14B00129 14P CONNECTOR 1
A5 K1KB31AA0140 31P CONNECTOR 1
A6 K1KA12AA0194 12P CONNECTOR 1
A7 K1KA09AA0193 9P CONNECTOR 1
A11 K1KA30B00078 30P CONNECTOR 1
A12 K1KA04AA0190 4P CONNECTOR 1
A17 K1KA20AA0009 20P CONNECTOR 1
A18 K1KA11AA0715 11P CONNECTOR 1
A30 K1KA05AA0193 5P CONNECTOR 1
A51 K1KA11A00178 11P CONNECTOR 1
A52 K1KA14A00248 14P CONNECTOR 1
AMM1-M5 TMME292 CLAMPER 5
C10 K1MN30BA0255 30P CONNECTOR 1
C11,12 K1MN68BA0266 68P CONNECTOR 2
C20 K1MN30BA0255 30P CONNECTOR 1
C21 K1MN68BA0266 68P CONNECTOR 1
C23 K1KA10B00218 10P CONNECTOR 1
C25 K1KA04BA0107 4P CONNECTOR 1
C858,59 ECJ2VB1E104K C 0.1UF, K, 25V 2
C860 ECA1EHG471 E 470UF, 25V 1
C861,62 ECJ2VB1E104K C 0.1UF, K, 25V 2
C869 ECA1EHG471 E 470UF, 25V 1
C1102 F1J1A106A043 C 0.010UF, K,
10V
1
C1103,04 F1G1C104A116 C 0.10UF, K, 16V 2
C1106 F1G1H270A731 E 27UF, 50V 1
C1107 F1G1H220A731 E 22UF, 50V 1
C1108 F1G1C104A116 C 0.10UF, K, 16V 1
C1109 F1H1A1050032 E 10UF, 50V 1
C1111 F1H1A1050032 E 10UF, 50V 1
C1112 F1G1C104A116 C 0.10UF, K, 16V 1
C1114 F1G1C104A116 C 0.10UF, K, 16V 1
C1117 F1G1C104A116 C 0.10UF, K, 16V 1
C1122 F1G1E103A123 C 0.010UF, K,
16V
1
C1123 F1H1A1050032 E 10UF, 50V 1
C2023 F1G1C104A116 C 0.10UF, K, 16V 1
C2048-50 F1G1C104A116 C 0.10UF, K, 16V 3
C2052,53 F1G1C104A116 C 0.10UF, K, 16V 2
C2054 F1J1A106A043 C 0.010UF, K,
10V
1
C2055 F1G1H120A731 E 12UF, 50V 1
C2056 F1G1H150A731 E 15UF, 50V 1
C2058 F1G1C104A116 C 0.10UF, K, 16V 1
C2059 F1J1A106A043 C 0.010UF, K,
10V
1
C2100 F1G1C104A116 C 0.10UF, K, 16V 1
C2101 F1J1A106A043 C 0.010UF, K,
10V
1
C2105,06 F1G1C104A116 C 0.10UF, K, 16V 2
C2107,08 F1J1A106A043 C 0.010UF, K,
10V
2
C2111 F1H0J2250008 C 2.2UF, K, 16V 1
C2116 F1G1H471A731 E 470UF, 50V 1
C2118 F1H1A1050032 E 10UF, 50V 1
C2126 F1J1A106A043 C 0.010UF, K,
10V
1
C2180,81 F1G1E103A123 C 0.010UF, K,
16V
2
C2186 F1G1C104A116 C 0.10UF, K, 16V 1
C2187 F1H0J2250008 C 2.2UF, K, 16V 1
C2188 F1G1H471A731 E 470UF, 50V 1
C2189 F1H1A1050032 E 10UF, 50V 1
C2190 F1J1A106A043 C 0.010UF, K,
10V
1
C2192 F1J1A106A043 C 0.010UF, K,
10V
1
C2195-98 F1G1E103A123 C 0.010UF, K,
16V
4
C2213 F1G1H102A730 E 1000UF, 50V 1
C2216 F1G1C104A116 C 0.10UF, K, 16V 1
C2244 F1G1C104A116 C 0.10UF, K, 16V 1
C2245 F1G1H102A730 E 1000UF, 50V 1
C2251 F1J1A106A043 C 0.010UF, K,
10V
1
C2263,64 F1J1A106A043 C 0.010UF, K,
10V
2
C2301,02 F1G1C104A116 C 0.10UF, K, 16V 2
C2303 F1J1E105A171 C 1 UF 25V 1
C2305 F1J1E105A171 C 1 UF 25V 1
C2307 F1J1E105A171 C 1 UF 25V 1
C2309 F1J1E105A171 C 1 UF 25V 1
C2313 F1H1A1050032 E 10UF, 50V 1
C2317 ECJ1VB1H104K C 0.1UF, K, 50V 1
C2319 ECJ1VB1H104K C 0.1UF, K, 50V 1
C2321 ECJ1VB1H104K C 0.1UF, K, 50V 1
C2323 ECJ1VB1H104K C 0.1UF, K, 50V 1
C2333 F1J1E3340003 C 0.33UF, Z, 25V 1
C2335 F1J1E3340003 C 0.33UF, Z, 25V 1
C2337 F1H1H223A970 C 0.22UF, K, 50V 1
C2339 F1H1H223A970 C 0.22UF, K, 50V 1
C2341 F1J1E3340003 C 0.33UF, Z, 25V 1
C2343 F1J1E3340003 C 0.33UF, Z, 25V 1
C2345 F1H1H223A970 C 0.22UF, K, 50V 1
C2347 F1H1H223A970 C 0.22UF, K, 50V 1
C2353 ECJ1VB1H104K C 0.1UF, K, 50V 1
C2359 ECJ1VB1H104K C 0.1UF, K, 50V 1
C2375 F1H1H223A970 C 0.22UF, K, 50V 1
C2377 F1H1H223A970 C 0.22UF, K, 50V 1
C2379 F1H1H223A970 C 0.22UF, K, 50V 1
C2381 F1H1H223A970 C 0.22UF, K, 50V 1
C2383 F1G1H102A730 E 1000UF, 50V 1
C2385 F1G1H102A730 E 1000UF, 50V 1
C2387 F1G1H102A730 E 1000UF, 50V 1
C2389 F1G1H102A730 E 1000UF, 50V 1
C2512 ECJ3XB0J106M C 10UF, M,6.3V 1
C2515 F1H1H103A970 C 0.001UF, K,
50V
1
C2521 F1H1H103A970 C 0.001UF, K,
50V
1
C3001 F1J1A106A043 C 0.010UF, K,
10V
1
C3006-08 F1J1A106A043 C 0.010UF, K,
10V
3
C3010,11 F1G1C1030008 C 0.010UF, K,
16V
2
C3013 F1J1A106A043 C 0.010UF, K,
10V
1
C3015,16 F1J1A106A043 C 0.010UF, K,
10V
2
C3017 F1G1C104A116 C 0.10UF, K, 16V 1
C3019 F1G1C104A116 C 0.10UF, K, 16V 1
C3020 F2G1C220A022 E 22UF, 16V 1
C3021 F2G1A221A149 E 220UF, 10V 1
C3022 F1G1C104A116 C 0.10UF, K, 16V 1
C3023 F1J1A106A043 C 0.010UF, K,
10V
1
C3024-35 F1H1A1050032 E 10UF, 50V 12
