Applicable input signals
1: Based on SMPTE 274M standard.
 2: Based on SMPTE RP211 standard.
 3: Based on SMPTE 295M standard.
4: When selected the RGB format and 525p signal input to the Mini D-sub 15P terminal, it is recognized as VGA 60Hz signal.
5: When inputted VGA 60Hz format signal from the other than Mini D-sub 15P terminal, it is recognized as 525p signal.
Note: Signals without above speci cation may not be displayed properly.
For TH-42PH12L, TH-50PH12L
VIDEO input (VIDEO, S VIDEO)
Signal name
Horizontal Vertical
frequency(kHz) frequency(Hz)
1 NTSC 15.73 59.94
2 PAL 15.63 50.00
3 PAL60 15.73 59.94
4 SECAM 15.63 50.00
5 Modi ed NTSC 15.73 59.94
*Mark: Applicable input signal
Signal name Horizontal frequency (kHz) Vertical frequency (Hz)
COMPONENT/RGB IN, PC IN
(Dot clock (MHz))
1 525 (480) / 60i 15.73 59.94
*
(13.5)
2 525 (480) / 60p 31.47 59.94
*
(27.0) 4
3 625 (575) / 50i 15.63 50.00
*
(13.5)
4 625 (575) / 50p 31.25 50.00
*
(27.0)
5 750 (720) / 60p 45.00 60.00
*
(74.25)
6 750 (720) / 50p 37.50 50.00
*
(74.25)
7 1,125 (1,080) / 60p 67.50 60.00
*
(148.5) 1
8 1,125 (1,080) / 60i 33.75 60.00
*
(74.25) 1
9 1,125 (1,080) / 50p 56.26 50.00
*
(148.5) 1
10 1,125 (1,080) / 50i 28.13 50.00
*
(74.25) 1
11 1,125 (1,080) / 24sF 27.00 47.92
*
(74.25) 2
12 1,125 (1,080) / 30p 33.75 30.00
*
(74.25) 1
13 1,125 (1,080) / 25p 28.13 25.00
*
(74.25) 1
14 1,125 (1,080) / 24p 27.00 24.00
*
(74.25) 1
15 1,250 (1,080) / 50i 31.25 50.00
*
(74.25) 3
16 640 × 400 @70 Hz 31.46 70.07
*
(25.17)
17 640 × 480 @60 Hz 31.47 59.94
*
(25.18) 5
18 640 × 480 @72 Hz 37.86 72.81
*
(31.5)
19 640 × 480 @75 Hz 37.50 75.00
*
(31.5)
20 640 × 480 @85 Hz 43.27 85.01
*
(36.0)
21 852 × 480 @60 Hz 31.47 59.94
*
(33.54) 5
22 800 × 600 @56 Hz 35.16 56.25
*
(36.0)
23 800 × 600 @60 Hz 37.88 60.32
*
(40.0)
24 800 × 600 @72 Hz 48.08 72.19
*
(50.0)
25 800 × 600 @75 Hz 46.88 75.00
*
(49.5)
26 800 × 600 @85 Hz 53.67 85.06
*
(56.25)
27 1,024 × 768 @60 Hz 48.36 60.00
*
(65.0)
28 1,024 × 768 @70 Hz 56.48 70.07
*
(75.0)
29 1,024 × 768 @75 Hz 60.02 75.03
*
(78.75)
30 1,024 × 768 @85 Hz 68.68 85.00
*
(94.5)
31 1,152 × 864 @75 Hz 67.50 75.00
*
(108.0)
32 1,280 × 768 @60 Hz 47.70 60.00
*
(80.14)
33 1,280 × 960 @60 Hz 60.00 60.00
*
(108.0)
34 1,280 × 960 @85 Hz 85.94 85.00
*
(148.5)
35 1,280 × 1,024 @60 Hz 63.98 60.02
*
(108.0)
36 1,280 × 1,024 @75 Hz 79.98 75.03
*
(135.0)
37 1,280 × 1,024 @85 Hz 91.15 85.02
*
(157.5)
38 1,600 × 1,200 @60 Hz 75.00 60.00
*
(162.0)
39 1,600 × 1,200 @65 Hz 81.25 65.00
*
(175.5)
40 1,066 × 600 @60 Hz 37.64 59.94
*
(53.0)
41 1,366 × 768 @60 Hz 48.36 60.00
*
(86.71)
42 Macintosh13” (640 × 480) 35.00 66.67
*
(30.24)
43 Macintosh16” (832 × 624) 49.72 74.54
*
(57.28)
44 Macintosh21” (1,152 × 870) 68.68 75.06
*
(100.0)
