Panasonic TH-80LFB70E - 3 Service Navigation; Service Hint

6
TH-80LFB70E
3 Service Navigation
3.1. Service Hint
Board Name Function
P-Board Power supply
Non serviceable.
P-Board should be exchanged for service.
A-Board Digital Signal Processor
DS-Board Slot Interface
HX-Board Speaker Terminal, PC OUT/RS232C
H1-Board USB Terminal
V1-Board Power LED Remote Receiver, C.A.T.S. Sensor
V2-Board Control Panel
