8
Connections
AC cord connection and xing, cable xing
TH-85VX200W
1
2
Note:
Two xing bands are supplied with this unit. In case of securing cables at three positions, please purchase it separately.
– Cable xing bands
Secure any excess cables with bands as required.
Pass the attached cable
xing band through the
clip as shown in the
gure.
To secure cables connected to Terminals, wrap the cable xing band around them
then pass the pointed end through the locking block, as shown in the gure.
While ensuring there is suf cient slack in cables to minimize stress (especially
in the power cord), rmly bind all cables with the supplied xing band.
To tighten:
To loosen:
Pull
Pull
Push the catch
Note:
Make sure that the
AC cord is locked on both
the left and right sides.
Push until
the hook clicks.
2. Pull off.
1. Keep the
knob pressed.
– AC cord xing
Unplug the AC cord
Unplug the
AC cord
pressing the
two knobs.
Note:
When disconnecting the AC
cord, be absolutely sure to
disconnect the AC cord plug
at the socket outlet rst.
Close
Open
Plug the AC cord into
the display unit.
Plug the AC cord until
it clicks.
Fix the AC cord with
the clamper.
2
1
To Next Page
