Panasonic TK-CJ600 - Installation

EN25EN24
English
Faucets without an aerator
Important ⿟Do not use a tool to tighten up the nut.
(Doing so may damage the nut.)
⿟Please store any unused parts instead of disposing of
them.
(They may be used when relocating or replacing the
faucet.)
1
Remove the nut and adaptor.
Nut
Adaptor
(with gasket)
Main unit
gasket
Filter
⿟Do not remove
Store
instead of
disposing.
2
Insert the installation adaptor
with screws removed in place of
the adaptor, and gently tighten
the nut.
Installation
Adaptor
(with 4 screws)
Tighten
gently by
hand
3
Loosely tighten the screws, and
loosen the nut.
Loosely tighten
the screws (x4).
Until there is
a 3 mm or
4 mm gap
3 mm to
4 mm
Proceed to Step 4
on the next page
Upon completion of installation, check that the main unit does not easily rotate and that there is no
play.
Accessories used
Installation
Adaptor
(with 4 screws)
Installation 4
InstallingtheWaterPurier(continued)
