Panasonic TK-CJ600 - Checking the Faucet; Installation 2

EN17EN16
English
3
Close the battery cover.
① Align the installation position.
② Push and turn the unpuried water
outlet cover clockwise to the lock
position.
②
①
Mounting
position
Fixed
position
■
Battery replacement timing
Replace the battery when the battery
replacement mark ( ) appears on the
LCD.
It is almost time to
replace the battery.
Flashes
The battery needs to be
replaced.
Please replace it with a
new battery.
Lights up
Note
⿟Approximate battery life
• About 1 year
• The battery included in the package is for
test use and may have a short life.
⿟Replacement battery
• This product uses the commercially
available, coin type lithium battery CR2032.
⿟Replacing the battery will not reset the
cartridge replacement guideline.
Installation 3
Checking the Faucet
⿟Bear in mind that Panasonic will not be liable for any product malfunctioning or accidents which
result from the failure to install or operate the product properly.
Faucets onto which the product can be installed
⿟Faucets with a thread on the outside
Thread diameter: 22 mm
Installing the Water Purier (P. EN20 – EN21)
6 mm or
more
Outside
thread
6 mm or
more
⿟Faucets with a thread on the inside
Thread diameter: 24 mm
Installing the Water Purier (P. EN22 – EN23)
Inside
thread
⿟Faucets without an aerator
Installing the Water Purier (P. EN24 – EN26)
<Flared faucets>
more than 10 mm
Flared:
13 mm or more, less than 24 mm
<Straight faucets>
more than 10 mm
Diameter of faucet end:
13 mm or more, less than 24 mm
Installation 2
TK-CJ600
Insert (replace) a Lithium Battery into the
Main Unit (continued)
