Panasonic TX-32LE7FA - Page 19

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COILL833 EXCELSA39V
COIL L1100 ELJFC2R2KFB
COIL L1101 ELJFC2R2KFB
COIL BLM18PG121SN1DL1380 J0JHC0000045
COIL L1381 ELJPA1R0MF
COIL L1500 TALV35VB100K
COIL TALL08T100KAL1501 G0A100GA0013
COIL L1502 TALV35VB100K
COIL L1503 TALV35VB100K
COIL L1504 TALV35VB100K
COIL TALL08T100KAL1505 G0A100GA0013
COIL L1506 TALV35VB100K
COIL L1507 TALV35VB100K
COIL L1509 TALV35VB100K
COIL TALL08T100KAL1514 G0A100GA0013
COIL TALL08T100KAL1515 G0A100GA0013
COIL L1518 J0JHC0000078
COIL L1519 J0JHC0000078
COIL L1520 J0JHC0000078
COIL L3021 ELJFCR68KFB
COIL L3022 ELJFCR68KFB
COIL L3023 ELJFCR68KFB
COIL L3024 ELJFCR68KFB
COIL L3025 ELJFCR68KFB
COIL L3026 ELJFCR68KFB
INDUCTOR L3028 J0JCC0000241
COIL L3600 ELJFA6R8KFB
COIL L3601 ELJFA6R8KFB
COIL L3800 G0A220ZA0041
COIL L3801 ELL6SH100ME
COIL L3802 ELLATV6R8N
COIL L3803 J0JJC0000015
COIL L3804 J0JJC0000015
COIL BLM18PG121SN1DL5000 J0JHC0000045
COIL BLM18PG121SN1DL5001 J0JHC0000045
COIL BLM18PG121SN1DL5002 J0JHC0000045
COIL L5003 J0JHC0000034
COIL L5004 J0JHC0000034
COIL L5005 J0JHC0000034
COIL L5006 J0JHC0000034
COIL BLM18PG121SN1DL5007 J0JHC0000045
COIL BLM18PG121SN1DL5010 J0JHC0000045
COIL L5013 J0JCC0000166
FILTERS
LINE FILTER LF800 G0B253G00007
LINE FILTER LF802 G0B253G00007
CRYSTALS
CRYSTAL X1500 AI202504E
CRYSTAL X5000 H0J283500018
RESISTORS
SMDJA10 ERJ12Y0R00 - - 0 ȍ
S.M.CARBJA90 ERJ6GEY0R00 0.1W - 0 ȍ
SMDJSA276 ERJ3GEY0R00 0.1W - 0 ȍ
SMDJSA330 ERJ3GEY0R00 0.1W - 0 ȍ
S.M.CARBR104 ERJ6GEYJ101 0.1W 5% 100 ȍ
S.M.CARBR105 ERJ6GEYJ101 0.1W 5% 100 ȍ
S.M.CARBR106 ERJ6GEYJ101 0.1W 5% 100 ȍ
SMDR121 ERJ3GEY0R00 0.1W - 0 ȍ
SMDR123 ERJ3GEY0R00 0.1W - 0 ȍ
S.M.CARBR124 ERJ6GEYJ223 0.1W 5% 22K ȍ
SMDR125 ERJ3GEYJ103 0.1W 5% 10K ȍ
SMDR126 ERJ3GEYJ272 0.1W 5% 2K7 ȍ
SMDR129 ERJ3GEY0R00 0.1W - 0 ȍ
SMDR130 ERJ3GEYJ332 0.1W 5% 3K3 ȍ
SMDR131 ERJ3GEYJ681V 0.1W 5% 680 ȍ
SMDR132 ERJ3GEYJ101 0.1W 5% 100 ȍ
SMDR133 ERJ3GEYJ102 0.1W 5% 1K ȍ
S.M.CARBR134 ERJ6GEY0R00 0.1W - 0 ȍ
SMDR135 ERJ3GEYJ471 0.1W 5% 470 ȍ
SMDR201 ERJ3GEYJ222 0.1W 5% 2K2 ȍ
S.M.CARBR202 ERJ3GEYJ473V 0.1W 5% 47K ȍ
SMDR203 ERJ3GEYJ105 0.1W 5% 1M ȍ
SMDR204 ERJ3GEYJ102 0.1W 5% 1K ȍ
S.M.CARBR205 ERJ3GEYJ392V 0.1W 5% 3K9 ȍ
S.M.CARBR206 ERJ6GEY0R00 0.1W - 0 ȍ
SMDR207 ERJ3GEYJ102 0.1W 5% 1K ȍ
SMDR208 ERJ3GEYJ101 0.1W 5% 100 ȍ
SMDR209 ERJ3GEYJ222 0.1W 5% 2K2 ȍ
S.M.CARBR210 ERJ6GEYJ100 0.1W 5% 10 ȍ
SMDR211 ERJ8GEYJ153 0.25W 5% 15K ȍ
S.M.CARBR213 ERJ6GEYJ223 0.1W 5% 22K ȍ
S.M.CARBR214 ERJ6GEYJ103 0.1W 5% 10K ȍ
SMDR215 ERJ3GEYJ222 0.1W 5% 2K2 ȍ
S.M.CARBR216 ERJ3GEYJ473V 0.1W 5% 47K
ȍ
SMDR217 ERJ3GEYJ105 0.1W 5% 1M ȍ
SMDR218 ERJ3GEYJ102 0.1W 5% 1K ȍ
S.M.CARBR219 ERJ3GEYJ392V 0.1W 5% 3K9 ȍ
S.M.CARBR220 ERJ6GEY0R00 0.1W - 0 ȍ
SMDR221 ERJ3GEYJ102 0.1W 5% 1K ȍ
SMDR222 ERJ3GEYJ101 0.1W 5% 100 ȍ
SMDR223 ERJ3GEYJ222 0.1W 5% 2K2 ȍ
S.M.CARBR224 ERJ6GEYJ100 0.1W 5% 10 ȍ
SMDR225 ERJ8GEYJ153 0.25W 5% 15K ȍ
S.M.CARBR228 ERJ6GEYJ473 0.1W 5% 47K ȍ
S.M.CARBR229 ERJ6GEYJ473 0.1W 5% 47K ȍ
S.M.CARBR241 ERJ6GEY0R00 0.1W - 0 ȍ
S.M.CARBR242 ERJ6GEY0R00 0.1W - 0 ȍ
S.M.CARBR243 ERJ6GEY0R00 0.1W - 0 ȍ
S.M.CARBR244 ERJ6GEY0R00 0.1W - 0 ȍ
SMDR246 ERJ3GEY0R00 0.1W - 0 ȍ
SMDR250 ERJ3GEYJ103 0.1W 5% 10K ȍ
SMDR251 ERJ3GEYJ103 0.1W 5% 10K ȍ
SMDR252 ERJ3GEYJ103 0.1W 5% 10K ȍ
S.M.CARBR254 ERJ3GEYJ473V 0.1W 5% 47K ȍ
SMDR258 ERJ3GEY0R00 0.1W - 0 ȍ
SMDR265 ERJ3GEYJ471 0.1W 5% 470 ȍ
SMDR266 ERJ3GEYJ471 0.1W 5% 470 ȍ
S.M.CARBR267 ERJ3GEYJ104V 0.1W 5% 100K ȍ
S.M.CARBR268 ERJ3GEYJ104V 0.1W 5% 100K ȍ
SMDR272 ERJ3GEYJ102 0.1W 5% 1K ȍ
SMDR273 ERJ3GEYJ102 0.1W 5% 1K ȍ
SMDR274 ERJ3GEYJ562 0.1W 5% 5K6 ȍ
S.M.CARBR275 ERJ6GEYJ681 0.1W 5% 680 ȍ
S.M.CARBR276 ERJ6GEYJ681 0.1W 5% 680 ȍ
SMDR277 ERJ3GEYJ102 0.1W 5% 1K ȍ
SMDR278 ERJ3GEYJ332 0.1W 5% 3K3 ȍ
SMDR279 ERJ3GEYJ332 0.1W 5% 3K3 ȍ
S.M.CARB
R280 ERJ3GEYJ104V 0.1W 5% 100K ȍ
S.M.CARBR281 ER
J3GEYJ104V 0.1W 5% 100K ȍ
SMDR282 ERJ6RBD103V 0.1W 0.5 10K ȍ
SMDR283 ERJ6RBD103V 0.1W 0.5 10K ȍ
S.M.CARBR284 ERJ6GEYJ473 0.1W 5% 47K ȍ
SMDR285 ERJ6RBD103V 0.1W 0.5 10K ȍ
S.M.CARBR286 ERJ6GEYJ473 0.1W 5% 47K ȍ
S.M.CARBR287 ERJ6GEYJ473 0.1W 5% 47K ȍ
SMDR288 ERJ6RBD103V 0.1W 0.5 10K ȍ
S.M.CARBR289 ERJ6GEYJ473 0.1W 5% 47K ȍ
S.M.CARBR290 ERJ6GEYJ472 0.1W 5% 4K7 ȍ
SMDR291 ERJ3GEYJ103 0.1W 5% 10K ȍ
SMDR292 ERJ3GEYJ332 0.1W 5% 3K3 ȍ
SMDR295 ERJ3GEYJ222 0.1W 5% 2K2 ȍ
S.M.CARBR299 ERJ3GEYJ104V 0.1W 5% 100K ȍ
SMDR303 ERJ3GEY0R00 0.1W - 0 ȍ
CARBONR800 ERC12ZGK105V 0.5W 10% 1M ȍ
CARBONR801 ERDS1FJ224T 0.5W 5% 220K ȍ
19
