Panasonic TX-32LE7FA - Self-Check

Self Check
Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To enter Self-Check mode, keep
pressing the STATUS button on the remote control and press the down (-/v) button on the TV set. To exit Self Check,
switch off the TV set at the power button.
9
E2CRC 56
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 FD
OPTION 8 D8
OPTION 9 00
OPTION 10 00
OPTION 11 13
OPTION 12 20
OPTION 13 1C
CHECK 42
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 09
Size 32
VCTP B3
TX-32LE7FA
Display Ref. No. Description P.C.B.
E2 IC1120 EAROM A-Board
VCTP IC1501 AUDIO VIDEO TEXT PROCESSOR A-Board
AVSW IC1501 AV SWITCH A-Board
TUN TU001 TUNER B-Board
HDMI IC1503 HDMI A-Board
If the CCU
p
orts have been checked and found to be incorrect or not located then " - - " will a
pp
ear in
p
lace of "O.K.".
E2CRC CC
OPTION 1 0D
OPTION 2 00
OPTION 3 39
OPTION 4 10
OPTION 5 00
OPTION 6 45
OPTION 7 3C
OPTION 8 58
OPTION 9 00
OPTION 10 40
OPTION 11 13
OPTION 12 28
OPTION 13 0C
CHECK B6
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 12
Size 32
VCTP B3
Self Check Com
p
lete
Panasonic 2007LCD
TX-32LE7LA
E2CRC 5F
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 FD
OPTION 8 58
OPTION 9 00
OPTION 10 00
OPTION 11 13
OPTION 12 20
OPTION 13 1C
CHECK C2
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 10
Size 32
VCTP B3
Self Check Com
p
lete
Panasonic 2007LCD
TX-32LE7PA
E2CRC 3E
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 FD
OPTION 8 58
OPTION 9 00
OPTION 10 00
OPTION 11 13
OPTION 12 40
OPTION 13 1C
CHECK E2
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 13
Size 26
VCTP B3
Self Check Com
p
lete
Panasonic 2007LCD
TX-26LE7PA
E2CRC AD
OPTION 1 0D
OPTION 2 00
OPTION 3 39
OPTION 4 10
OPTION 5 00
OPTION 6 45
OPTION 7 3C
OPTION 8 58
OPTION 9 00
OPTION 10 40
OPTION 11 13
OPTION 12 48
OPTION 13 0C
CHECK D6
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 08
Size 26
VCTP B3
Self Check Com
p
lete
Panasonic 2007LCD
TX-26LE70LA
E2CRC 3D
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 FD
OPTION 8 D8
OPTION 9 00
OPTION 10 00
OPTION 11 13
OPTION 12 40
OPTION 13 1C
CHECK 62
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 14
Size 26
VCTP B3
Self Check Com
p
lete
Panasonic 2007LCD
SW V1.12
E2 V02
SW V1.12
E2 V02
TV V1.12
E2 V02
TV V1.12
E2 V02
TV V1.12
E2 V02
TX-26LE7FA
Self Check Com
p
lete
SW V1.12
E2 V02
Panasonic 2007LCD
E2CRC 31
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 FD
OPTION 8 58
OPTION 9 00
OPTION 10 00
OPTION 11 13
OPTION 12 20
OPTION 13 1C
CHECK C2
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 19
Size 32
VCTP B3
Self Check Com
p
lete
Panasonic 2007LCD
TX-R32LE7A
E2CRC 16
OPTION 1 0F
OPTION 2 00
OPTION 3 B9
OPTION 4 11
OPTION 5 00
OPTION 6 45
OPTION 7 FD
OPTION 8 58
OPTION 9 00
OPTION 10 00
OPTION 11 13
OPTION 12 40
OPTION 13 1C
CHECK E2
E2 O.K.
VCTP O.K.
AVSW O.K.
TUN O.K.
HDMI O.K.
Chassis 21
Model 20
Size 26
VCTP B3
Self Check Com
p
lete
Panasonic 2007LCD
TV V1.12
E2 V02
TV V1.12
E2 V02
TX-R26LE7A
