Technical Description
Specification of KEY for CI Plus, DTCP-IP and One-to-One
General information:
1. EEPROM (IC8950) for spare parts has the seed of KEY for each.
2. The final KEY data will be generated by sLD IC (IC8001) when SELF CHECK was done and are stored in both sLD IC
(IC8001) and EEPROM (IC8950).
Three KEY are not generated for all models.
The necessary KEY are only generated and stored depend on the feature of models.
Replacement of ICs:
When sLD IC (IC8001) is replaced, EEPROM (IC8950) should be also replaced with new one the same time.
When EEPROM (IC8950) is replaced, sLD IC (IC8001) is not necessary to be replaced the same time.
After the replacement of IC, SELF CHECK should be done to generate the final KEY data.
How to SELF CHECK: While pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote
control for more than 3 seconds.
TV will be forced to the factory shipment setting after this SELF CHECK.
Model and Keys:
Keys
Model No.
CI PLUS DTCP-IP
One-to_one
(for USB Rec.)
TX-L32C2B None None None
TX-L32C2E Yes None None
