Panasonic TX-L32C2E - Self Check

Self Check

Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To enter Self-Check mode, keep

pressing the down (-/v) button on the TV set and press the STATUS button on the remote control. To exit Self Check,

switch off the TV set at the power button.

* Displayed for E model only

Display Ref. No. Description P.C.B.

TUN TU2901A TUNER A-Board

STBY IC8001 sLD /STM/ A-Board

MEM1 IC1101 EEPROM /STM/ A-Board

MEM2 IC8950 EEPROM /sLD/ A-Board

ADAM IC8001 A-chip /sLD/ A-Board

AVSW IC3000 AUDIO VIDEO SWITCH A-Board

OFDM IC8300 DVB-T/C DEMODULATOR A-Board

VIF TU2901A TUNER A-Board

TCON-EEP IC8001 sLD A-Board

TCON-DCDC IC4800 DC/DC CONVERTER A-Board

TCON-DAC IC4802 TCON GAMMA DAC A-Board

*ID IC8950 EEPROM /sLD/ A-Board

If the CCU

p

orts have been checked and found to be incorrect or not located then " - - " will a

pp

ear in

p

lace of "O.K.".

12

TX-L32C2B

32HD Panasonic 2010LCD

Self Check Com

p

lete

TUN O.K.

STBY O.K.

MEM1 O.K.

MEM2 O.K..

ADAM O.K.

AVSW O.K.

OFDM O.K.

VIF O.K.

TCON-EEP O.K.

TCON-DCDC O. K.

TCON-DAC O.K.

PEAKS-SOFT 1.015

PEAKS-EEP 01.01.0024

LSI-PACKAGE 0.032

LSI-RELEASE 1.08

STBY-SOFT 1.00.00

STBY-EEP 1.01.3500

STBY-ROMCORR 0.00.00

SUM C55A

MODEL ID 07

03156100

00000004

EDID 20 4b------

TX-L32C2E
