Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type number to your order.
Replacement Parts List
Important Safety Notice
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
RTL (Retention Time Limited)
Note:
X
The marking (X) indicates that board should be exchanged for service.
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
TUNER 1 ENG37F03KF
CONTROL BUTTON UNIT 2 K0RB00600015
SPEAKER UNIT 3 L0AA14B00006
LCD PANEL 4 L5EDD8Q00063
POWER UNIT 5 N0AC4GJ00011
REMOTE CONTROL 6 N2QAYB000487
PEDESTAL ASSY FIX 7 TBL0E0108
STAND MTG ASSY 8 TBL0E0122
PANASONIC BADGE 9 TBMA352
CONNECTOR COVER 10 TKP0E16001
AC CORD BRACKET 11 TKP0E39001
SPEAKER BRACKET L 12 TKX0E6001
SPEAKER BRACKET R 13 TKX0E6101
SIDE MASK BRACKET 14 TKZ0EA5026
BOTTOM MASK BRACKET 15 TKZ0EA5030
VERTICAL SUPPORT BRACK 16 TKZ0EC5004
LCD BTM MTG BRACKET 17 TKZ0EC5007
LCD TOP BRACKET L 18 TKZ0EC5011-1
LCD TOP BRACKET R 19 TKZ0EC5012-1
VESA WALL MTG BRACKET 20 TKZ0EE5004
A-PCB MTG SMALL 21 TKZ0EG5019
A-PCB MTG LARGE 22 TKZ0EG5022
SPEAKER RUBBER BUSH 23 TMM4GJ004
V P.C.B. 24 TNP8EV102AE
SIDE AV ASSEMBLY 25 TTP0E0107
BACK COVER ASSY 26 TTU0E0681
CABINET ASSY 27 TTY0E0604
MISCELLANEOUS COMPONENTS
BATTERY . R6DB/2P
SIDE AV LABEL . TBM0E9052
SCREW . THEJ024
SCREW . THEL044N
SCREW. THTD020J
IR/LED WINDOW . TKP0E39201
FELT . TMK0EA040
CLAMPER . TMME332
P-PCB CLAMPER . TMME378
CLAMPER . TMME379
CARTON CAP . TPG0E9480A
SCREW . XTB4+12JFJK
SCREW . XTV3+8JFJK
SCREW . XTW3+10TFJ
SCREW . XYN4+F12FJK
BOTTOM CUSHION BOTCUS TPD0E2123
CARTON CARTON TPC0EA00101B
THERMAL PAD_A/D FA01 TMKK398
THERMAL PAD_DDR FA02 TMKK389
TOP CUSHION TOPCUS TPD0E1124-1
I.C.s
EEPROM STM IC1101 24GLP25STM
AUDIO AMPLIFIER IC2301 C1AB00003230
REGULATOR IC2950 C0CBCAG00031
REGULATOR IC2952 C0DBGYY00281
AUDIO VIDEO SWITCHIC3000 C1AB00003218
DC/DC CONVERTER IC4800 C0DBZYY00343
TCON GAMMA DAC IC4802 C0FBBF000074
ANALOG ASIC IC5000 AN34042A-VF
REGULATOR IC5200 C0DBEYY00123
REGULATOR IC5220 C0DBGYY00895
REGULATOR IC5416 C0DBGYY00281
DC/DC CONVERTER IC5600 C0DBAYY00715
DC/DC CONVERTER IC5601 C0DBAYY00715
REGULATOR IC5603 C0DBFYY00049
REGULATOR IC5604 C0DBGYY00578
IC SLD IC8001 MN2WS0125FE
DVB-T/C DEMODULATORIC8300 C1AB00003188
REGULATOR IC8302 C0DBFYY00041
CI TS ASIC IC8400 C1AB00003193
LEVEL SHIFTER IC8401 C1AB00002913
IC SWITCH IC8402 C0ZBZ0001584
FLASH MEMORY IC8921 TVRR431AN
LED RECEIVER RM2500 B3RAD0000168
FUSES
FUSE PA4800 K5H1622A0031
FUSE PA4801 ERBSE1R50U
FUSE PA4802 ERBSE1R50U
FUSE PA5260 ERBSE5R00U
FUSE PA5601 ERBSE5R00U
DIODES
DIODE D1100 B0JCCE000008
DIODE D1101 B0JCCE000008
LED D2500 B3AGB0000060
VARISTOR D2758 EZJZ0V120JA
ZENER DIODE D2766 DZ2J140M0L
ZENER DIODE D2768 DZ2J140M0L
DIODE D2770 B0ACCJ000048
DIODE D2771 B0ACCJ000048
DIODE D2772 B0ACCJ000048
DIODE D2773 B0ACCJ000048
VARISTOR D2774 EZJZ0V120JA
