Setting Inspection
Voltage Confirmation
Confirm the following voltages:
A board
Description Test point Position Voltage
SUB1.8V TP5601 L5601 1.75V – 1.87V
SUB1.2V TP5600 L5600 1.18V – 1.3V
SUB3.3V TP5602 L5604 3.18V – 3.4V
SUB5V TP5200 C5203 4.86V – 5.13V
SUB9V TP5220 IC5220, pin 1 8.82V – 9.27V
STB5V TP5400 IC5416, pin5 4.85V - 5.15V
11
