Intermediate Frequency:
Video/Audio C2B C2E
Video 38.9MHz 38.9MHz, 33.9MHz
Audio 32.90MHz 33.4MHz (B/G), 33.16MHz (A2)
32.35MHz(NICAM) 33.05MHz (NICAM B/G, D/K, L)
32.4MHz (D/K), 32.66MHz (CZ STEREO)
40.4MHz (L
’), 39.75MHz (L’NICAM)
Colour 34.47MHz 34.47MHz (PAL)
34.5MHz, 34.65MHz (SECAM)
38.3MHz, 38.15MHz (SECAM L
’)
Terminals:
AV1 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin) 0.7V p-p 75Ω
S-video IN (21-pin) Y: 1V p-p 75Ω
C:0.3V p-p 75Ω
AV1 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV2 IN Video (RCAx1) 1V p-p 75Ω
AUDIO IN Audio (RCAx2) 500mV rms 10kΩ (used for HDMI_ COMPONENT-AUDIO)
COMPONENT Video (RCAx3) Y:1V p-p 75Ω (including synchronization)
Pb, Pr: ±0.35V p-p 75Ω
HDMI Type A Connectors
HDMI
(Version 1.4 with Audio Return Channel))
This TV supports “HDAVI Control 5” function.
C2B C2E
DIGITAL AUDIO OUT PCM / Dolby digital, PCM / Dolby digital / DTS
Fiber optic Fiber optic
C2B C2E
CARD SLOT SD CARD slot x1 SD CARD slot x1
Common interface slot x1 Common interface slot (Complies with CI+) x1
LCD screen: L5EDD8Q00063
1,366 x 768, 16:9
Visible Diagonal 800mm
Audio Output: 10W (2 x 5W), 10% THD
Headphones: 3.5mm, 8Ω Impedance
Accessories supplied : Remote Control 2 x R6 (UM3) Batteries
Dimensions:
Height: Width: Depth:
Including TV stand 551mm 798mm 217mm
TV set only 511mm 798mm 87mm
Mass:
Including TV stand 11.0kg
TV set only 9.5kg
Specifications are subject to change without notice.
Mass and dimensions shown are approximate.
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
Warning
