Panasonic TX-L32C2E - Page 36

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC8097 F1G1C104A116 16V 100nF
S.M.CAPC8098 F1G1C104A116 16V 100nF
CERAMICC8099 F1H0J1050013 6.3V 1µF
S.M.CAPC8100 F1J1A106A087 10V 10µF
S.M.CAPC8101 F1J1A106A087 10V 10µF
CERAMICC8102 F1H0J1050013 6.3V 1µF
CERAMICC8103 F1H0J1050013 6.3V 1µF
CERAMICC8104 F1H0J1050013 6.3V 1µF
S.M.CAPC8105 F1G1C104A116 16V 100nF
S.M.CAPC8106 F1G1C104A116 16V 100nF
S.M.CAPC8107 F1G1C104A116 16V 100nF
S.M.CAPC8108 F1G1C104A116 16V 100nF
S.M.CAPC8109 F1G1C104A116 16V 100nF
S.M.CAPC8110 F1G1C104A116 16V 100nF
S.M.CAPC8111 F1G1C104A116 16V 100nF
S.M.CAPC8112 F1G1C104A116 16V 100nF
S.M.CAPC8113 F1G1C104A116 16V 100nF
S.M.CAPC8114 F1G1C104A116 16V 100nF
S.M.CAPC8115 F1G1C104A116 16V 100nF
S.M.CAPC8116 F1G1C104A116 16V 100nF
S.M.CAPC8117 F1G1C104A116 16V 100nF
S.M.CAPC8118 F1J1A106A087 10V 10µF
S.M.CAPC8119 F1G1C104A116 16V 100nF
S.M.CAPC8120 F1G1C104A116 16V 100nF
S.M.CAPC8121 F1G1C104A116 16V 100nF
S.M.CAPC8122 F1G1C104A116 16V 100nF
S.M.CAPC8123 F1G1C104A116 16V 100nF
S.M.CAPC8124 F1J1A106A087 10V 10µF
S.M.CAPC8125 F1J1A106A087 10V 10µF
S.M.CAPC8126 F1J1A106A087 10V 10µF
CERAMICC8127 F1H0J1050013 6.3V 1µF
S.M.CAPC8300 F1G1C104A116 16V 100nF
S.M.CAPC8301 F1G1C104A116 16V 100nF
S.M.CAPC8303 F1G1C104A116 16V 100nF
S.M.CAPC8304 F1G1H100A731 50V 10pF
S.M.CAPC8305 F1G1H100A731 50V 10pF
S.M.CAPC8306 F1G1C104A116 16V 100nF
S.M.CAPC8308 F1G1C104A116 16V 100nF
S.M.CAPC8309 F1G1C104A116 16V 100nF
S.M.CAPC8310 F1G1C104A116 16V 100nF
S.M.CAPC8311 F1J1A106A087 10V 10µF
S.M.CAPC8314 F1G1C104A116 16V 100nF
S.M.CAPC8315 F1G1C104A116 16V 100nF
S.M.CAPC8316 F1G1C104A116 16V 100nF
S.M.CAPC8317 F1G1C104A116 16V 100nF
S.M.CAPC8318 F1G1C104A116 16V 100nF
S.M.CAPC8319 F1G1C104A116 16V 100nF
S.M.CAPC8320 F1H1A105A025 10V 1µF
S.M.CAPC8321 F1H1A225A051 10V 2200nF
S.M.CAPC8322 F1G1C104A116 16V 100nF
S.M.CAPC8324 F1G1H560A731 50V 56pF
S.
M
.CAPC8325 F1G1H560A731 50V 56pF
S.M.CAPC8400 F1G1C104A116 16V 100nF
S.M.CAPC8401 F1G1C104A116 16V 100nF
S.M.CAPC8402 F1G1C104A116 16V 100nF
S.M.CAPC8403 F1G1C104A116 16V 100nF
S.M.CAPC8404 F1G1C104A116 16V 100nF
S.M.CAPC8405 F1G1C104A116 16V 100nF
S.M.CAPC8406 F1G1C104A116 16V 100nF
S.M.CAPC8407 F1G1C104A116 16V 100nF
S.M.CAPC8408 F1G1C104A116 16V 100nF
S.M.CAPC8409 F1G1C104A116 16V 100nF
S.M.CAPC8410 F1G1C104A116 16V 100nF
ELECTC8411 F2H1A101A009 10V 100µF
S.M.CAPC8412 F1G1C104A116 16V 100nF
S.M.CAPC8413 F1G1E103A123 25V 10nF
S.M.CAPC8414 F1G1E103A123 25V 10nF
S.M.CAPC8415 F1G1C104A116 16V 100nF
S.M.CAPC8600 F1G1H102A730 50V 1nF
S.M.CAPC8853 F1G1C104A116 16V 100nF
S.M.CAPC8854 F1G1C104A116 16V 100nF
ELECTC8860 F2G1C470A022 16V 47µF
S.M.CAPC8861 F1G1C104A116 16V 100nF
S.M.CAPC8862 F1G1C103A116 16V 10nF
S.M.CAPC8863 F1J0G226A001 4V 22µF
S.M.CAPC8922 F1G1C104A116 16V 100nF
S.M.CAPC8923 F1G1C104A116 16V 100nF
S.M.CAPC8950 F1G1C103A116 16V 10nF
TERMINALS AND LINKS
PLUG . K4ZZ02000104
WIRE ASSY . TXJA010QEA
4P CONNECTOR A02 K1KY04AA0719
15P CONNECTOR A09 K1KA15AA0409
A09-P2 WIRE A09-P2 TXJA09QSB-2
8P CONNECTOR A10 K1KY08AA0719
4P CONNECTOR A12 K1KA04AA0190
55P CONNECTOR A14 K1MN55BA0076
LVDS WIRE A14-PAN K1PY55Y00001
8P CONNECTOR CN0100 K1KA08AA0714
OPT TERMINAL D3300 K7AAAY000006
HP TERMINAL JK3251 K2HC104B0051
YUV_AUDIO IN_V INJK3301D K2HA6YYA0004
SCART TERMINAL JK3303 K1FY121A0009
HDMI CONNECTOR JK4700 K1FY119D0012
CI SLOT JK8401 K1NA68B00053
SD SLOT JK8850 K1NA12E00017
8P CONNECTOR V10 K1KA08B00270
DIFFERENCES FOR MODEL TX--L32C2B
EXPLODED VIEW
A P.C.B. 28 A-L32C2B
AC CORD 29 TXASX01QTB-3
CI SLOT COVER SHEET 30 TBM0E1709
MODEL LABEL 31 TBM0E2344
MISCELLANEOUS COMPONENTS
REAR AV LABEL . TBM0E9074
INSTRUCTION BOOKS
ENGLISH . TQB0E2021
I.C.s
EEPROM SLD IC8950 X24CL32C2B
DIFFERENCES FOR MODEL TX--L32C2E
EXPLODED VIEW
A P.C.B. 28 A-L32C2E
AC CORD 29 TXASX01QSB-3
MODEL LABEL 31 TBM0E2343
MISCELLANEOUS COMPONENTS
REAR AV LABEL . TBM0E9073
INSTRUCTION BOOKS
GERMAN . TQB0E2020A
DUTCH . TQB0E2020B
ITALIAN . TQB0E2020C
FRENCH . TQB0E2020D
SPANISH . TQB0E2020E
SWEDISH . TQB0E2020F
NORWEGIAN . TQB0E2020G
FINNISH . TQB0E2020H
LITHUANIAN . TQB0E2020I
PORTUGUESE . TQB0E2020J
DANISH . TQB0E2020K
BULGARIAN . TQB0E2020M
36
