Model No. : TX-P50C3E/J, PR50C3 Parts List
Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
PCB N0AE5JK00007 CIRCUIT BOARD P 1 PAVCCZ
PCB A-P50C3E CIRCUIT BOARD A 1 (RTL)PAVCCZ P50C3E
PCB A-P50C3J CIRCUIT BOARD A 1 (RTL)PAVCCZ P50C3J
PCB A-PR50C3 CIRCUIT BOARD A 1 (RTL)PAVCCZ PR50C3
PCB TXN/K1RLUE CIRCUIT BOARD K 1 (RTL)PAVCCZ
PCB TXNC111LGK CIRCUIT BOARD C1 1 (RTL)PAVCCZ
PCB TXNC211LGK CIRCUIT BOARD C2 1 (RTL)PAVCCZ
PCB TXNSN11LGK CIRCUIT BOARD SN 1 (RTL)PAVCCZ
PCB TXNSS11LGK CIRCUIT BOARD SS 1 (RTL)PAVCCZ
A1 K1KY08AA0719 8P CONNECTOR 1
A6 K1KY15B00006 15P CONNECTOR 1 PAVCCZ
A11 K1KY04B00013 4P CONNECTOR 1 PAVCCZ
A23 K1MY30BA0345 30P CONNECTOR 1
A33 K1MY35BA0345 35P CONNECTOR 1
A34 K1MY35BA0345 35P CONNECTOR 1
A35 K1KY03AA0719 3P CONNECTOR 1
C0059 F1G1H1020008 C 1000PF 50V 1
C0071 F1G1H1020008 C 1000PF 50V 1
C0072 F1G1H1020008 C 1000PF 50V 1
C0074 F1G1H1020008 C 1000PF 50V 1
C0075 F1G1H1020008 C 1000PF 50V 1
C1050 F1G1C104A077 C 0.1UF 16V 1
C1051 F1J0G2260001 C 22 UF 4 V 1
C1053 F1J0G2260001 C 22 UF 4 V 1
C2003 F1J1A106A087 C 10UF, 10V 1
C2004 F1J1E105A231 C 1 UF 25V 1
C2006 F1G1E1030005 C 0.01UF 25V 1
C2008 F1J1H102A721 C 1000pF, 50V 1
C2009 F1G1E1030005 C 0.01UF 25V 1
C2014 F1G1C104A077 C 0.1UF 16V 1
C2026 F1G1H1020008 C 1000PF 50V 1
C2027 F1G1C104A077 C 0.1UF 16V 1
C2810 ECJ1VB1H103K C 0.01UF, 50V 1
C2811 F1J1A106A087 C 10UF, 10V 1
C2815 ECJ1VB1H103K C 0.01UF, 50V 1
C2821 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C3001 F1G1A105A047 C 1UF 10V 1
C3002 F1G1A105A047 C 1UF 10V 1
C3003 F1G1C104A077 C 0.1UF 16V 1
C3004 F1G1C104A077 C 0.1UF 16V 1
C3005 F1G1A105A047 C 1UF 10V 1
C3006 F1G1A105A047 C 1UF 10V 1
C3011 F1J1A106A043 C 10UF, 10V 1
C3016 F1G1C104A077 C 0.1UF 16V 1
C3018 F1G1C104A077 C 0.1UF 16V 1
C3019 F1G1C104A077 C 0.1UF 16V 1
C3020 F1J1A106A043 C 10UF, 10V 1
C3028 F1J1A106A087 C 10UF, 10V 1
C3084 F1J1A106A043 C 10UF, 10V 1
C3085 F1J1A106A043 C 10UF, 10V 1
C3086 F1J1A106A043 C 10UF, 10V 1
C3108 F1G1E333A091 C 0.033UF 25V 1
C3109 F1G1E333A091 C 0.033UF 25V 1
C3120 F2H1A101A040 E 100UF, 10V 1 PAVCCZ
C3121 F2H1A101A040 E 100UF, 10V 1 PAVCCZ
C3124 F1J1A106A043 C 10UF, 10V 1
C3130 F1J1A106A043 C 10UF, 10V 1
C3131 F1J1A106A043 C 10UF, 10V 1
C3132 F1J1A106A043 C 10UF, 10V 1
C3135 F1G1H5610004 C 560 pF 50 V 1 PAVCCZ
S-35
