Panasonic TX-P50C3E - Page 85

Model No. : TX-P50C3E/J, PR50C3 Parts List
Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
L9302 J0JHC0000117 CHIP INDUCTOR 1
L9303 J0JHC0000117 CHIP INDUCTOR 1
L9800 G1C6R8MA0445 INDUCTION COIL 1 PAVCCZ
PA2011 K5H5022A0031 FUSE 1
Q0900 DSA200100L TRANSISTOR 1
Q2810 B1ABCE000015 TRANSISTOR 1
Q2811 B1ABCE000015 TRANSISTOR 1
Q2812 B1ABCE000015 TRANSISTOR 1
Q3102 B1ABCF000231 TRANSISTOR 1
Q3103 B1ABCF000231 TRANSISTOR 1
Q4513 DSA200100L TRANSISTOR 1
Q4514 B1HFCEA00001 TRANSISTOR 1 PAVCCZ
Q4700 B1ABCF000231 TRANSISTOR 1
Q4702 B1ABCF000231 TRANSISTOR 1
Q4970 DSA200100L TRANSISTOR 1
Q4971 B1AAFB000002 TRANSISTOR 1
Q4972 B1AAFB000002 TRANSISTOR 1
Q4973 DSA2001S0L TRANSISTOR 1
Q4974 DSC2001S0L TRANSISTOR 1
Q5170 DSC2001S0L TRANSISTOR 1
Q5171 DSA200100L TRANSISTOR 1
Q5172 DSA200100L TRANSISTOR 1
Q8100 B1MBEDA00027 FET 1 PAVCCZ
Q8102 B1MBEDA00027 FET 1 PAVCCZ
R003 D0GBR00J0004 M 0 OHM J 1/10W 1
R0800 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R0902 D0GA473JA015 M 47KOHM, J,1/16W 1
R0903 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0904 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0905 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0906 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0907 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0908 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0909 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0910 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0911 EXB28V222J M 2.2 OHM 1/32 W 1
R0951 D0GA473JA015 M 47KOHM, J,1/16W 1
R0952 D0GA102JA023 M1KOHM, J.1/16 W 1
R1009 D0GA101JA015 M 100 OHM, J,1/16W 1
R2003 D0GA473JA015 M 47KOHM, J,1/16W 1
R2004 D1BA1432A014 M14.3KOHM,J.1/16 W 1 PAVCCZ
R2005 D1BA6651A014 M6.65KOHM,J.1/16 W 1 PAVCCZ
R2006 D1BA7151A014 M7.15KOHM,J.1/16 W 1
R2007 ERJ2RKF1741 M 1.74KOHM, F 1/16 W 1
R2008 D0GA184JA023 M 180KOHM J.1/16W 1
R2010 D1BA7151A014 M7.15KOHM,J.1/16 W 1
R2011 D0GA102JA023 M1KOHM, J.1/16 W 1
R2013 D0GA103JA015 M 10KOHM,J,1/16W 1
R2810 D0GB470JA065 M 47 OHM,J,1/10W 1 PAVCCZ
R2811 D0GB104JA065 M 100KOHM J 1/10W 1
R2812 D0GB224JA065 M 220KOHM,J,1/10W 1 PAVCCZ
R2813 D0GB223JA065 M 22KOHM,J,1/10W 1 PAVCCZ
R2814 D0GB103JA065 M 10K OHM J 1/10W 1 PAVCCZ
R2815 D0GB473JA065 M 47KOHM J. 1/10W 1 PAVCCZ
R2816 D0GA473JA015 M 47KOHM, J,1/16W 1
R2816 D1BB1621A055 M1.62KOHM,J.1/10W 1
R2817 D0GB223JA065 M 22KOHM,J,1/10W 1 PAVCCZ
R2818 D0GB473JA065 M 47KOHM J. 1/10W 1 PAVCCZ
R2819 D1BB4301A055 M4.30KOHM,J.1/10W 1
S-41
