Panasonic TX-P65VT60E - Local Screen Failure Diagnosis and PCB Defects

7.4.1 Drive circuits LED indicator
Check that the following LEDs on the SC and SS-Board.
7.5 Local screen failure
Plasma display may have local area failure on the screen. Fig-1 is the possible defect P.C.B. for each local area.
Fig-1
Power recovery
LED
LED for check
SC
D16583
SS
D16254A
