Main unit
1 Disc tray
2 Display (> below)
3 USB port ( DC 5 V 900 mA)
• This port supports USB 3.0 Super Speed.
4 Remote control signal sensor
• Angle: Approx. 20° up and down, 30° left and right
• Distance: Within approx. 7 m in front of the unit
5 CI slot (> 70)
6 Open/close disc tray
7 Standby/on switch (Í/I)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
1 Drive (HDD or BD) indicator
2 Disc indicator
3 Digital broadcast indicator
4 Copying indicator
5 USB port indicator
6 Remote control signal indicator
7 Timer recording indicator
This indicator lights up when the timer
recording standby or Keyword Recording
standby is activated.
8 Recording indicator
• The indicator will light up while recording.
• The indicator will blink while recording is
paused and before recording starts.
9 Main display section indicator
• Messages and other information are
displayed. (> 65)
: Playback indicator
Front
Pull to flip
down the front
panel.
Ensure that it is
facing the right way
up.
