Panasonic WV-CW634S

14
AUTO1
**D&N(IR) **(1)

LEVEL

HIGH

DURATION TIME

S L
BURST(BW)ON
RET TOP END
.
I
..
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD OFF
RET TOP END
D&N(IR)
“CAMERA SETUP” screen “D&N (IR)” screen
Step 1
Move the cursor to “D&N (IR)” and select the mode from the following.
AUTO1 (default): Automatically switches between color and black-and-white images in accordance with the illuminance. The
black-and-white mode is selected for dark images, and the color mode is selected for bright images.
AUTO2: Used a near-infrared light source at night time.
ON: Displays black-and-white images.
OFF: Displays color images.
Note:
• When “AUTO1” or “AUTO2” is selected, it is recommended to set “AGC” to “ON”.
• If a subject is always moving or the screen is occupied with a uniform color, brightness determination may not be performed suc-
cessfully because the brightness is merely determined by information from the CCD image sensor. When “AUTO2” is selected, the
wave length of the light source shall be 800 nm or longer.
Step 2
Press the [SET] button.
→
The “D&N (IR)” screen appears.
Step 3
Move the cursor to “LEVEL” and select a brightness level at which switching between color and black-and-white images is performed
from the following.
LOW: Switches from color to black-and-white images when the ambient illuminance of the camera is less than 0.1 lx.
HIGH (default): Switches from color to black-and-white images when the ambient illuminance of the camera is less than 0.2 lx.
Note:
• The switching illuminance level varies with subjects, light sources, and lenses.
• The switching illuminance level varies in accordance with AGC setting. (
+
page 11)
• The switching illuminances described above are reference values. The switching illuminance shall be decided based on the actual
installation environment.
• There may be repeated switching between color and black-and-white images depending on the setting and environment.
Step 4
Move the cursor to “DURATION TIME” and select a time for switching between color and black-and-white images from the following.
2 seconds - 10 seconds (default) - 30 seconds - 60 seconds
(S) (L)
Step 5
Move the cursor to “BURST (BW)”, and decide whether or not to provide a burst signal output in the black-and-white mode.
ON (default): Provides a burst signal output.
OFF: Does not provide any burst signal output.
