Getting Started
Installing/Removing SIM card and battery
1. To remove the battery cover, slide it as shown right.
2. Insert the SIM card into the slot. The gold contacts of the
SIM card should face down.
3. Slide the connector of the battery into the notch located
at the top of the unit. Insert (1) and press the lower side
of the battery until you hear a click (2). Make sure you
align the gold contacts on the battery end with the
contacts on the phone. If the contacts on the battery are
not properly aligned, the phone and the battery could be
damaged.
Correct Incorrect
