ParaBody 660 - Page 29

29
0
1
2
345
6
1/2 1/2 1/2 1/2 1/2 1/2
FIGURE 31
STEP 31
• Attach two 1 X 1" GUIDES (53) to the PRESS SWIVEL (10) approximately where shown in FIGURE 31.
• SECURE PRESS SWIVEL (10) to the post on the CALF/LOW ROW (2) using one STARLOCK COLLAR (50). See FIGURE 31.
2
53
10
POST
50
