FIGURE 50
STEP 50
• Assemble the ELASTIC CORD (67) from the PRESS CABLE to the SWIVEL SNAP (68) on the BASE as shown in FIGURE 50.
68
BASE
44
67 PRESS CABLE
ELASTIC CORD
