ParaBody 660 - Elastic Cord

FIGURE 46
STEP 46
• Attach three ELASTIC CORDS (67) to the three KEYHOLE CLEVIS (66)
as shown in FIGURE 46.
41
FIGURE 47
STEP 47
TOP BOOM
• Assemble the 72” ELASTIC CORD (67) from the PRESS CABLE around the 2” PULLEY (69) in the TOP BOOM as shown in FIGURE
47.
67
LEG EXT
CABLE
LAT CABLE
PRESS
CABLE
69
67
