42
FIGURE 48
STEP 48
TOP BOOM
• Assemble the 72” ELASTIC CORD (67) from the LEG CABLE around the 2” PULLEY (69) in the TOP BOOM as shown in FIGURE 48.
67
69
LEG EXT
CABLE
LAT CABLE
PRESS
CABLE
