Paradox MG5000 Programming Guide

34
Magellan & Spectra SP • Programming Guide
Wireless Keypad Signal Strength
The signal strength for wireless keypads is visible in sections [591] to [598]; these sections represent keypads 1 through 8, respectively. To view the signal strength,
proceed as follows:
1. Enter the wireless keypad’s respective section (e.g., for keypad 1, enter section [591]).
2. Press on the keypad. As shown in table 21, the number of beeps correspond to a preset signal strength range.
NOTE: The visual representation of a keypad’s signal strength is dependent on the type of keypad. For LED keypads, zones 1 through 10 will illuminate, depending
on the signal strength. For instance, a signal strength of 8 will result in zones 1 through 8 to illuminate. For LCD keypads, a ten-level progress bar composed of
arrows will appear, followed by the numeric value. For a signal strength of 8, eight arrows will appear, followed by the number 8.
Wireless Keypad Labels
Use worksheet 25 to record your settings for wireless keypad labels. To reset these labels, see Description of Section [965] on page 53.
NOTE: For special characters and keypad letter assignments, see Label Programming with LCD Keypads on page 54.
Remote Control Programming
Use the following section to program remote controls for your MG/SP control panel.
Remote Control Button Assignment
Use worksheet 26 on page 35 to record your settings when assigning remote controls to your MG/SP control panel. See table 22 for details on button options for
these remotes.
WARNING: Remote controls which are supported by MG/SP control panels are the following: REM1, REM2, RAC1, RAC2, REM3, and REM15.
NOTE: The disarm button ( ) cannot be modified.
Table 21: Signal strength indicator for wireless keypads
Number of Beeps Signal Strength Result
3 8 to 10 Strong signal
2 5 to 7 Average signal
1 1 to 4 Weak signal (relocate)
Worksheet 25: Wireless Keypad Labels
Section Description Wireless Keypad Label
[599] Keypad 1 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[600] Keypad 2 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[601] Keypad 3 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[602] Keypad 4 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[603] Keypad 5 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[604] Keypad 6 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[605] Keypad 7 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[606] Keypad 8 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
Table 22: Button options for MG/SP remote controls (see Decimal and Hexadecimal Programming on page 4)
Option Description Option Description
Sleep Empty/button disabled 8 Panic 1
1 Regular/regular force arming 9 Panic 2
2Stay/stay force arming APanic 3
3 - B PGM activation (event group 8)*
4 Sleep/sleep force arming C PGM activation (event group 9)*
5 PGM activation (event group 22)* D PGM activation (event group 10)*
6 PGM activation (event group 23)* E PGM activation (event group 11)*
7 Activate window mode (StayD) F Paramedic alarm
* For descriptions on the event groups, see Description of MG/SP Events on page 21.

Paradox MG5000 Specifications

General

Partitions	2
User Codes	32
Wireless Expansion	Yes
Remote Control	Yes
Event Buffer	256 events
Wireless Zones	32
Users	32
StayD Mode	Yes
Input Voltage	16.5 VAC
Number of Zones	32
Wireless	Yes
Supported Detectors	Paradox wireless detectors
Event Log	256 events
Zones	32
PGMs	2
Remote Controls	32
Reporting Methods	GSM, GPRS, IP
Battery Backup	12V 7Ah
