Omnia 15
For installations using a Spectra control panel version 2.0 or higher:
If you are having trouble assigning the remote control, the environment
may be too noisy. Therefore, we recommend that you assign the remote
controls before installing the detectors and door contacts.
6.2 ASSIGNING THE REMOTE CONTROLS TO USER ACCESS CODES
S
ECTIONS
[701]
TO
[708]:
Each remote control must be assigned to a User Access Code. All User Access Codes
are given a User Number from 001 to 048. Enter the desired User Number in a section
from [701] to [708] that represent the remote control assigned in sections [721]/[731] to
[728]/[738] (refer to section 6.1 on page 14). For example, the remote control assigned
in section [731] will be assigned to the User Access Code designated in section [701].
6.3 PROGRAMMING THE REMOTE CONTROL BUTTONS
S
ECTIONS
[711]
TO
[718]
Each remote control can be programmed to send a signal to the control panel to perform
up to 8 different actions. Each digit in sections [711] to [718] represents a button or
combination of buttons (refer to Table 6.1 on page 16). When a user arms or disarms
using the remote control, the control panel will arm or disarm all the areas assigned to
the User Access Code. For example, you arm with a remote control whose User Access
Code is assigned to areas 1 and 2, the control panel will attempt to arm areas 1 and 2.
How to assign a remote control to the receiver module (V2.0 and higher).
In step 3 in section 3.1 on page 6:
1. Enter desired [
SECTION NUMBER] (731 to 738).
2. Press any button on the remote control twice, or until the confirmation beep
sounds (“Beep-Beep-Beep-Beep-Beep”).
How to assign a remote control to a user access code.
In step 3 in section 3.1 on page 6:
1. Enter the desired [
SECTION
NUMBER
] (701 to 708).
2. Enter the User Number to be assigned to the remote control (001 to 048).
