Paradox omnia OMN-RCV3 User Manual

Omnia 7
3.2.1 A
SSIGNING
D
ETECTORS AND
D
OOR
C
ONTACTS TO THE
R
ECEIVER
SECTIONS
[601]
TO
[608]
In Spectra systems, up to 8 wireless transmitters (detectors and door
contacts) can be assigned to each Receiver Module. Section [601] to [608]
represent expansion inputs 1 to 8 respectively. For example, section [601] is
assigned to expansion input 1, section [602] is assigned to expansion input 2,
etc. (refer to Table 3.1). Each Expansion Input represents a specific zone in
the system depending on the type of Spectra control panel being used and
whether the ATZ option is enabled (refer to the appropriate Spectra control
panel Programming Guide).
Table 3.1: Sections and Expansion Inputs
Do not assign detection devices from different modules to the same
expansion input. For example, do not assign a wireless transmitter
to section [601], then connect a detection device to input Z1 of the
APR3-ZX8.
Section # 6-digit Serial Number Expansion Input
[601]
___/___/___/___/___/___ Input 1
[602]
___/___/___/___/___/___ Input 2
[603]
___/___/___/___/___/___ Input 3
[604]
___/___/___/___/___/___ Input 4
[605]
___/___/___/___/___/___ Input 5
[606]
___/___/___/___/___/___ Input 6
[607]
___/___/___/___/___/___ Input 7
[608]
___/___/___/___/___/___ Input 8
How to assign detectors & door contacts to the receiver module.
In step 3 in section 3.1 on page 6:
1. Enter the desired [
SECTION NUMBER
] (601 to 608).
2. Enter the 6-digit serial number of the detector or door contact.
