Magellan & Spectra SP • Installation Guide
Viewing the Repeater’s Signal Strength
Sections [548] to [549]
Once the repeaters have been installed and assigned to the control panel, the signal strength of each repeater can be verified in sections [548] to [549]. Section
[548] is the viewer for repeater 1 and section [549] is the viewer for the repeater 2. Sometimes moving the repeater or control panel by a small amount will greatly
increase the signal reception.
Wireless Repeater Options
Section [587]: Wireless Repeater Options
Option [1] OFF= Repeater 1 Supervision Disabled
Option [1] ON = Repeater 1 Supervision Enabled (default)
Option [2] OFF= Repeater 2 Supervision Disabled
Option [2] ON = Repeater 2 Supervision Enabled (default)
If enabled, the panel can wait for each of its assigned wireless transmitters to send a status signal within a specified time to confirm their presence and functionality.
Wireless Options
Section [551] (Repeater 1) and Section [561] (Repeater 2): Wireless Repeater Options
Enable or disable the repetition of wireless keypads in this section. Enabling these options for keypads means that the repeater will retransmit any signals relevant to them.
Option [1] OFF= Repeat Wireless Keypad 1 Signals (default)
Option [1] ON= Repeat Wireless Keypad 1 Signals
Option [2] OFF= Repeat Wireless Keypad 2 Signals (default)
Option [2] ON= Repeat Wireless Keypad 2 Signals
Option [3] OFF= Repeat Wireless Keypad 3 Signals (default)
Option [3] ON= Repeat Wireless Keypad 3 Signals
Option [4] OFF= Repeat Wireless Keypad 4 Signals (default)
Option [4] ON= Repeat Wireless Keypad 4 Signals
Option [5] OFF= Repeat Wireless Keypad 5 Signals (default)
Option [5] ON= Repeat Wireless Keypad 5 Signals
Option [6] OFF= Repeat Wireless Keypad 6 Signals (default)
Option [6] ON= Repeat Wireless Keypad 6 Signals
Option [7] OFF= Repeat Wireless Keypad 7 Signals (default)
Option [7] ON= Repeat Wireless Keypad 7 Signals
Option [8] OFF= Repeat Wireless Keypad 8 Signals (default)
Option [8] ON= Repeat Wireless Keypad 8 Signals
How Do I View a Wireless Transmitter’s Signal Strength?
1. Press the [
ENTER] key.
2. Enter your [
INSTALLER CODE] (default: 0000 / 000000) or [MAINTENANCE CODE] (empty by default)
3. Enter the desired [
SECTION NUMBER] (from sections [548] to [549]).
4. Press the repeater’s anti-tamper switch.
5. The keypad will illuminate numbers 1 to 10.
Signal Strength Indicator 8 to 10 / 3 beeps = Best signal 5 to 7 / 2 beeps = Average signal 1 to 4 / 1 beep = Weak signal (Relocate)
