32
Magellan & Spectra SP • Installation Guide
24 Hr. Freeze Zones
Sections [001] to [032]: Zones 1 to 32, First Digits = 21
When a 24Hr. Freeze zone opens, whether it is armed or disarmed, the control panel will immediately generate an alarm. This alarm is defined by the alarm type,
configured in Zone Programming under zone options [4] and [5]. See Alarm Types on page 33. The SIA FSK and CID reporting formats include specific report codes
to identify the alarm as a Freeze alarm.
24Hr. Panic
Sections [001] to [032]: Zones 1 to 32, First Digits = 22
When a 24Hr. Panic zone opens, whether it is armed or disarmed, the system will immediately generate an alarm. This alarm is defined by the panic options set in
section [702]. The SIA FSK and CID reporting formats include specific report codes to identify the alarm as a Panic alarm. Section [702] option [1] (Panic 1) must be
enabled for the 24Hr. Panic zone to function.
Instant No Pre-Alarm
Sections [001] to [032]: Zones 1 to 32, First Digits = 23
This zone definition ignores the Flex-Instant delay, and acts like a traditional Instant zone.
Follow No Pre-Alarm
Sections [001] to [032]: Zones 1 to 32, First Digits = 24
This zone definition ignores the Flex-Instant delay, and acts like a traditional Follow zone.
Zone Definition Status
There are eight zone definitions that are affected by the Flex-Instant delay (section [720]). The following table shows how the zone definition changes depending
on the arm status and if the Flex-Instant delay is enabled. See “Zone Definition Status” on page 32
Zone Partition Assignment
Sections [001] to [032]: Zones 1 to 32
The control panel provides the option of partitioning the security system into two completely independent systems. Sections [001] to [032] represent zones 1
through 32 respectively, where the third digit in each of these sections represents the zone's partition assignment.
The zone is assigned to Partition 1 if third digit = 1, Partition 2 if third digit = 2, or both partitions is third digit = 3. For more details, See “Partitioning” on page 58.
Zone Options
Sections [001] to [032] represent zones 1 through 32 respectively. After entering the definition and partition assignment, select one or more of the following Zone
Options by using the Multiple Feature Select Programming Method:
Zone Definitions Stay Arm Sleep Arm Fully Arm
01 = Entry Delay 1 Entry Delay 1 Entry Delay 1 Entry Delay 1
02 = Entry Delay 2 Entry Delay 2 Entry Delay 2 Entry Delay 2
03 = Entry Delay 1 (Full Arm)
Not Armed Not Armed Entry Delay 1
04 = Entry Delay 2 (Full Arm)
Not Armed Not Armed Entry Delay 2
05 = Follow Follow* Follow* Follow*
06 = Follow (Sleep/Full Arm)
Not Armed Follow* Follow
07 = Follow (Full Arm)
Not Armed Not Armed Follow
08 = Instant Instant* Instant* Instant*
09 = Instant (Sleep/Full Arm)
Not Armed Instant* Instant
10 = Instant (Full Arm)
Not Armed Not Armed Instant
23 = Instant No Pre-Alarm Instant Instant Instant*
24 = Follow No Pre-Alarm Follow Follow Follow*
* Flex-Instant = Zone will follow the delay at section [720], (default is 15 seconds / 0 = instant zone)
