Magellan & Spectra SP • Installation Guide
Specifications
All control panel outputs are rated to operate between 10.8Vdc and 12.1Vdc
MG5000 / MG5050 / MG5075
Power rating
MG5000/MG5050: 16.5 VAC (50 or 60Hz) minimum 20 VA (40 VA recommended)
MG5075: Internal Power Supply (75W) 110 - 220 VAC, 1A, 50-60 Hz
Wall Plug (60W) 15Vdc
Power consumption
MG5000: 1.2A(Max.), 85 mA (Idle) MG5050: 1.2A(Max.), 95 mA (Idle)
MG5075: 1A (Max.), 220 mA (Idle)
Aux. power *
MG5000/MG5050: 600 mA typical, 700 mA maximum, fuseless shutdown at 1.1A
MG5075: 15V, 2.5 maximum, fuseless shutdown at 3A
Battery 12 VDC, 4Ah/7Ah/24Ah
Battery charging current MG5000/MG5050: 350 mA MG5075: Up to 1.5A, 7Ah < 7 hrs, 24 Ah ~ 24 hrs
On-board zones MG5000: 2 MG5050/MG5075: 5
Bell output ** 1A (fuseless shutdown at 3A)
On-board PGMs
MG5000: 2
MG5050/MG5075: 4 (1+/- trigger)
All on-board PGMS are 100mA low-current outputs
Dimensions
MG5000: 19 x 10.2 cm (7.5 x 4 in.)
MG5050: 19 x 10.2 cm (7.5 x 4 in.)
MG5075: 18.5 x 8.9 cm (7.3 x 3.5 in.)
Weight MG5000: 170g MG5050: 154g MG5075: 143g
Operating temperature 0°C to 50°C (32°F to 122°F)
Humidity 5% - 90%
Standards
MG5050 and MG5075: EN 50131-1, EN 50131-3, EN 50131-6 Type A, Security Grade 2 Environmental Class II
EN 50136-1, EN 501036-2, EN 50131-10 ATS Category SP2
MG5050 Certification Body: Intertek
MG5075 Certification Body: Applica Test and Certification
* Cannot exceed 200 mA for UL installations
** Cannot exceed 1A for UL installations
SP4000 / SP5500 / SP6000 / SP65 / SP7000
Power rating 16.5 Vac (50 or 60 Hz) minimum 20 VA (40 VA recommended)
Power consumption
SP4000: 1.2A(Max.), 50 mA (Idle), SP5500: 1.2A(Max.), 70 mA (Idle), SP65: 1.2A(Max.), 66 mA (Idle)
SP6000: 1.7A(Max.), 100 mA (Idle), SP7000: 1.7A(Max.), 120 mA (Idle)
Aux. power
SP4000: 450 mA, fuseless shutdown at 600 mA
SP65: 500 mA, fuseless shutdown at 750 mA
SP5500 / SP60 00 / SP7000: 600 mA typical, 700 mA
maximum, fuseless shutdown at 1.1A
Battery 12 Vdc, 4 Ah/7 Ah
Battery charging current
SP4000 / SP65: Limited by 1.1A supply current (AUX
consumption - no dedicated battery current limit circuit)
SP5500: 350 mA
SP6000 / SP7000: 350 mA / 850 mA
On-board zones
SP4000: 4
SP5500: 5
SP6000: 8
SP65: 9
SP7000: 16
Bell output 1A (fuseless shutdown at 3A)
On-board PGMs
SP4000: 1
SP5500: 2
SP6000: 2+(2 optional) (all +/- trigger)
SP65: 3 (all +/- trigger)
SP7000: 4 (all +/- trigger)
All on-board PGMS are 100 mA low-current outputs
Dimensions
SP4000: 14 x 6.6 cm (5.5 x 2.6 in.)
SP5500: 19 x 9 cm (7.5 x 3.5 in.)
SP6000: 19 x 9 cm (7.5 x 3.5 in.)
SP65: 14 x 6.6 cm (5.5 x 2.6 in.)
SP7000: 20.1 x 10.7 cm (7.9 x 3.9 in.)
Weight
SP4000: 111g
SP5500: 153g
SP6000: 191g
SP65: 105g
SP7000: 219g
Operating temperature 0°C to 50°C (32°F to 122°F)
Humidity 5% - 90%
Standards
EN 50131-1, EN 50131-3, EN 50131-6 Type A, Security Grade 2
Environmental Class II/ Certification Body: Intertek
30hrs backup 60hrs backup Recharge to 80% (@350mA)
7AHr 150 mA 50 mA 20 hrs.
