Pari Compact - Technical Data; Technical Data General; Classification According to DIN EN 60601-1

- 19 -
en
6 TECHNICAL DATA
6.1 General
6.2 Classification according to DIN EN 60601-1
Supply voltage [V] 220 V – 240 V
Mains frequency [Hz] 50 Hz
Power consumption [A] 0.6 A
Housing dimensions [cm] 16 × 10 × 15
(W × H × D)
Compressor flow
1)
3.9 l/min
Sound pressure level
2)
approx. 58 dBA
Pressure: 1.1 bar
Weight 1.2 kg
1) towards PARI nebuliser nozzle (Ø 0.48 mm)
2) Maximum A-evaluated sound pressure level of the compressor
(acc. to: DIN EN 13544-1, section 26)
Type of electric shock protection Protection
class II
Degree of protection from electric shock of the
part used (nebuliser)
Type BF
Degree of protection against water ingress in
accordance with IEC 529 (IP rating)
No protection
Degree of protection when used in the presence
of flammable mixtures of anaesthetics with air,
with oxygen, or with nitrous oxide
No protection
Operating mode Continuous
operation
