Prop. Directional Control Valve
Series D*FB / D*1FB
Operation Manual
7
Parker Hannifin CorporationParker Hannifin Corporation
D_FB-D_1FB_10-12 5715-669 UK.indd 25.06.19
Technical Data
General
Model Proportional directional control valve, direct operated (D*FB),
pilot operated (D*1FB)
Drive Proportional solenoid
Mounting Pattern NG6 (CETOP 3) / NG10 (CETOP 5)
NG16 (CETOP 7) / NG25 (CETOP 8) / NG32 (CETOP 11)
Installation Position Any
Hysteresis D1FB*0/D3FB*0 [%] < 4
D3FB*3/D*1FB [%] < 5
Ambient Temperature Range [°C] -20...+60
MTTF
D
value [years] 150 (D*FB), 75 (D*1FB)
Protection Class NEMA 4 (IP 65) acc. EN 60529
Weight [kg] NG6: 3 / NG10: 7 / NG16: 11 / NG25: 19.5 / NG32: 61
Vibration Strength [g] 10 Sinus 5...2000 Hz acc. IEC 68-2-6
10 (RMS) Random noise 20...2000 Hz acc. IEC 68-2-36
15 Shock acc. IEC 68-2-27
Hydraulic
Operating Pressure max. (D*FB)
Pilot oil intern (D*1FB):
Pilot oil extern (D*1FB):
[bar]
[bar]
[bar]
350 for ports P, A, B / 210 for port T
350 for ports P, A, B, X / 185 for T, Y
350 for ports P, A, B, T, X / 185 for Y
Fluid Hydraulic oil according to DIN 51524...535, other on request
Fluid Temperature [°C] -20...+60 (NBR: -25...+60)
Viscosity permitted
[cSt]/[mm
2
/s]
20...400
Filtration ISO 4406; 18/16/13
Electrical
Duty Ratio [%] 100
Supply Voltage Us [VDC] 18...30, ripple <5% eff., surge free
Current Consumption max. [A] D1FB: 2.0 / D3FB: 3.5 / D*1FB: 2.0
Pre-Fusing [A] D1FB: 2.5 / D3FB: 4.0 / D*1FB: 2.5
Potentiometer supply Up [V] ± 10 / ± 5 % max. 10 mA
Command Signal Options Uc
Ic
[V]
[mA]
[mA]
Codes F0, M0, W5: +10...0...-10, ripple <0.01 % eff., surge free,
Ri = 100 kOhm
Codes S0 & W5: 4...12...20, ripple <0.01 % eff., surge free,
Ri = <250 Ohm
< 3.6 mA = enable off, > 3.8 mA = enable on (acc. NAMUR NE43)
Code G0: +20...0...-20, ripple <0.01 % eff., surge free,
Ri = <250 Ohm
Differential Input Voltage max. [V]
Codes F0, M0, S0, G0: 30 for terminal D and E against PE (terminal G)
[V] 11 for terminal D and E against 0 V (terminal B)
[V]
Code W5: 30 for terminal 4 and 5 against PE (terminal W)
[V] 11 for terminal 4 and 5 against 0 V (terminal 2)
Channel Recall Signal Uch [V] 0...2.5: Off / 5...30: On / Ri = 100 kOhm
Adjustment Ranges Min [%] 0...50
Max [%] 50...100
Ramp [s] 0...32.5
Interface RS 232C, parametrizing connection 5pole
EMC EN 61000-6-2, EN 61000-6-4
Central Connection Codes F0, M0, S0, G0: 6 + PE acc. EN 175201-804
Code W5: 11 + PE acc. EN 175201-804
Cable Specification [mm²] Codes F0, M0, S0, G0: 7 x 1.0 (AWG16) overall braid shield
[mm²] Code W5: 11 x 1.0 (AWG16) overall braid shield
Cable Length max. [m] 50
