2. Technical data
2.1. Main hardware specifications
The maximum voltage value is 480Vac (instead of former 460Vac). Ensure that the maximum
voltage across terminals L1, L2, L3 does not exceed more than 10% the 480Vac, even in the
worst case (see EN60204-1 standard, section 4.3.1). An excessive voltage may damage the
drive. The following table describes the new ratings:
Description Unit Value
Mains voltage V~ 90…480
Models
HPD2N HPD5N HPD8N HPD16N HPD20N HPD24N
Rated current A 2 5 8 16 20 25
Peak current (4 seconds) A 4 10 16 32 65 50
Input current FLA 1.6 4.2 6.2 12 15 19
Rated motor torque (@400 V~) KW 1 2.5 4.1 8.3 10 12.5
Control-stage power dissipation W 18
Power-stage dissipation W 25 60 89 158 200 246
Enviromental temperature o
C
45
Braking resistor internal / external
Internal braking resistor power dissipation W 120 240
Feedback resolver (speed 1)
Power-stage switching frequency KHz 8
Max. output frequency Hz 450
Protection Grade IP 20
Digital Inputs 24V =
N
o 8
Digital Outputs 24V = / 100mA / PNP
N
o 6
Digital Output “Voltage-Free”
N
o 1
Encoder Simulation RS-422 steps/rev 128..16384
Frequency/sign Input or ext. Encoder KHz 800 / 200
Analogue reference V ±10 diff 15 bits
Aux. Analogue Input V ±10 diff 10 bits
Aux. Analogue Output V ±10 - 8 bits
Tacho Output V ±10 V
Serial link RS-422 / RS-485
Encoder Simulation Backup V 24 =
Encoder Simulation Backup A max. 2
