“N” Series Valves
Electrical Connections
Catalog 0600P-10/USA
Technical Information
Automotive Connections
• 3-Pin & 5-Pin “Mini” (7/8 UNF Thread)
• 4-Pin “Micro” (M12 Thread)
Solenoid Configurations
“E”, “J”, “N”
Wiring Connections
1
2 3
4
SOLENOID
COIL
4-PIN MICRO
(TOP COVER)
1
2
3
4
5
SOLENOID
COIL
5-PIN MINI
(TOP COVER)
Chrysler Connection
5-Pin Male/Single Solenoid
(Encl. Option N, Wiring Option C)
4-Pin Male/Single Solenoid
(Encl. Option J, Wiring Option C)
2
SOLENOID
COIL
4-PIN MICRO
(TOP COVER)
1
2
3
4
5
SOLENOID
COIL
5-Pin Male/Single Solenoid
(Encl. Option N, Wiring Option F)
4-Pin Male/Single Solenoid
(Encl. Option J, Wiring Option F)
3-Pin Male/Single Solenoid
(Encl. Option E, Wiring Option F)
5-PIN MINI
(TOP COVER)
1
3
4
Ford Connection
2
SOLENOID
COIL
1
3
GRN
(+) Signal
(-) Common
GRN
GRN
NOT USED NOT USED
NOT USED
NOT USED
NOT USED NOT USED
NOT USED
GRN
NOT USED NOT USED
NOT USED
(-) Common
(+) Signal
(-) Common
(+) Signal
(-) Common
(+) Signal
GRN
NOT USED
(-) Common
(+) Signal
(-) Common
(+) Signal
(-) Common
(+) Signal
SOLENOID
COIL
4-PIN MICRO
(TOP COVER)
1
2
3
4
5
SOLENOID
COIL
5-PIN MINI
(TOP COVER)
GM Connection
5-Pin Male/Single Solenoid
(Encl. Option N, Wiring Option G)
4-Pin Male/Single Solenoid
(Encl. Option J, Wiring Option G)
1
2 3
4
