Parker "N" Series User Manual

Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
M17
M
EXH
1/2 NPT
Conduit
Connection
P
N
K
J
H
L Travel
M
G
H100-60
H175-12
K183-001*
H100-59
H175-12
H100-60
H175-12
K183-001*
H100-59
H 175-12
A
A
F
B
E
D
D
C
On 2-Way Valve This
Port Is Plugged
On 2-Way Valve This
Port Is Plugged
12
11*
2
1
6
8
9
13
3*
4*
5
7*
14
10
12
11*
2
6
8
9
13
3*
4*
5
1A
7*
10A
EXH
1/2 NPT
Conduit
Connection
CYL.
IN
CYL.
IN
P
R
R
Q
K
J
H
L Travel
M
G
A
A
A
B
E
D
D
C
“N” Series Valves
Internal Pilot - 3/8" & 3/4" Basic Body
Catalog 0600P-10/USA
Dimensions - Single Solenoid
Key 3/8" Valve 3/4" Valve Description
5 K493 002 K493 009 Stem
6 K202 001 K202 002 Lower Piston Assy.
7* H145 09 H136 76 U-Cup (3/8), O-Ring (3/4)
8 H178 11 H178 13 Washer (2)
9 H063 26 H063 32 Stop Nut (2)
10 K103 035 K103 053 Bottom Cap (N.C.)
10A K092 020 K092 034 Bottom Cap Assy. (N.O.)
11* K183 049 K183 057 Gasket
12 K473 014 K473 015 Spring
13 K563 015 K563 017 Adapter
14* K41RB72121 K41RB72221 O-Ring
* Parts included in seal kit
Key 3/8" Valve 3/4" Valve Description
1
—
1/2" Tap
K053 075
Body (N.C.)
3/8" Tap
K053 022
3/4" Tap
K053 076
1/2" Tap
K053 023
1" Tap
K053 220
1A
—
3/4" Tap
K053 077
Body (N.O.)
3/8" Tap
K053 025
3/4" Tap
K053 078
1/2" Tap
K053 026
1" Tap
K053 218
2 K212 001 K212 002 Upper Piston Assy
3* H136 48 H137 28 Seal
4* H145 10 H136 76 U-Cup (3/8), O-Ring (3/4)
Normally Closed
Key
3/8" Body 3/4" Body
Inch mm Inch mm
A
1.56 40 2.13 54
B
1.50 38 1.94 49
C
1.81 46 1.34 34
D
.56 14 .56 14
E
3/8-16UNC
7/16" deep
3/8-16UNC
9/16" deep
F
1.75 44 2.25 57
G
1.50 38 1.50 38
H
5.92 150 7.14 181
J
3.19 81 3.75 95
K
1.88 47 2.44 62
L
.11 3 .16 4
M
.50 13 .50 13
N
1.44 37 1.78 45
P
7.36 196 8.58 218
Q
2.31 59 3.09 84
R
7.92 201 8.83 224
Top view indicates flow through 3-Way
valve with coil de-energized.
NOTE: For normal valve operation, override
must be in “out” position.
Service Kits
Include all parts normally required for
in-service maintenance:
3/8" Basic Valve with standard
service L-Pilots ................K352 076
3/8" Basic Valve with continuous
duty L-Pilots ....................K352 276
3/4" Basic Valve with standard
service L-Pilots ................K352 077
3/4" Basic Valve with continuous
duty L-Pilots ....................K352 277
Dimensions
Exhaust
Pressure
Normally Open
