Parker "N" Series User Manual

Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
M6
M
Catalog 0600P-10/USA
Model Number Index
“N” Series Valves
Inline Poppet Valve – Solenoid Operated
“N” Series 3/8", 3/4" & 1-1/4" Body Sizes - Solenoid ‘L’ Pilot
BOLD OPTIONS ARE MOST POPULAR.
Valve Function - Solenoid
3/8" & 3/4" Body
2-Way, Normally Closed 315
3-Way, Normally Closed 355
3-Way, Normally Open 375
1-1/4" Body
2-Way, Normally Closed 325
3-Way, Normally Closed 365
3-Way, Normally Open 385
N 315 3 9 0 45 53 —
Options
Blank None
L 72" Leads - ‘51’ Voltage Code Only
C Chrysler Wiring - Enclosure ‘J’ & ‘N’
F Ford Wiring - Enclosure ‘E’, ‘J’, & ‘N’
G GM wiring - Enclosure ‘J’ & ‘N’
Port Size / Thread Type
3/8" Body Size
3/8" Inlet & Cyl - 1/2" Exhaust - NPT 3
1/2" Inlet & Cyl - 1/2" Exhaust - NPT 4
1/2" Inlet & Cyl - 1/2" Exhaust - BSPP N
3/4" Body Size
1/2" Inlet & Cyl - 3/4" Exhaust - NPT 5
3/4" Inlet & Cyl - 1" Exhaust - NPT 6
3/4" Inlet & Cyl - 1" Exhaust - BSPP Q
1" Inlet & Cyl - 1" Exhaust - NPT 7
1-1/4" Body Size
1" Inlet & Cyl - 1 1/4"Exhaust - NPT 7
1-1/4" Inlet & Cyl – 1-1/2" Exhaust - NPT 8
1-1/4" Inlet & Cyl – 1-1/2" Exhaust - BSPP S*
1-1/2" Inlet & Cyl – 1-1/2" Exhaust - NPT 9
1-1/2" Inlet & Cyl – 1-1/2" Exhaust - BSPP T*
* Not available with Valve Function 325.
Note: BSPP is to the ISO 228 Standard, and
requires an R-BSPT male fitting.
Solenoid Enclosure
Basic Pilot 1
Basic Pilot NLMO 2
Basic Pilot LMO 3
Junction Box NLMO 5
Junction Box LMO 6
Junction Box NLMO w/ Light 8
Junction Box LMO w/ Light 9
Basic Pilot Ext. LMO W
JIC NLMO w/Light - 3-Pin Automotive E
JIC NLMO w/ Light - 4-Pin M12 J
JIC NLMO w/ Light - 5-Pin Automotive N
“L” Pilot Code
Code
Voltage Solenoid Enclosure Options
AC
60hz
AC
50hz
DC
Standard Duty
(01, 45)
Cont. Duty
(04, 48)
200 PSI
(46)
42 24 24 6 5, 6 6
45 12 1, 5, 6
49 24
1, 2, 3, 5, 6, 8,
9, W
6, 8, 9 9
51 48 1
53 120 110
1, 2, 3, 5, 6, 8,
9, E, N, W
1, 6, 8, 9, N 8, 9, E
57 240 220 1, 3, W
61 120 5, 6
79 24 E, J E, J E, J
Solenoid Type
0 Standard
5* Hazardous Duty
8* NEMA 4 Solenoid
* Available with Solenoid Enclosure 2 & 3, ‘L’
Pilot Configuration 04 & 48,
and Voltage 49 & 53 ONLY.
“L” Pilot Configuration
01* External Pilot, Std Service, 140 PSI
04* External Pilot, Cont Duty, 140 PSI
45 Internal Pilot, Std Service, 140 PSI
46 Internal Pilot, Std Service, 200 PSI
48 Internal Pilot, Cont Duty, 140 PSI
* Not available with Valve Function 325, 365,
and 385 (1-1/4" Body).

Parker "N" Series Specifications

General

Series	N
Category	Plumbing Product
Type	Needle Valve
Material	Brass
Connection Type	NPT
Temperature Rating	-65°F to 250°F
