“N” Series Valves
Internal Pilot - 1-1/4" Basic Body
Catalog 0600P-10/USA
Dimensions - Single Solenoid
Key 1-1/4" Valve Description
5 K493 016 Stem
6 K313 028 Lower Piston
7* H137 28 Seal
8 H178 17 Washer
9 H063 38 Stop Nut
10 K092 046 Bottom Cap (N.C.)
10A K103 061 Bottom Cap (N.O.)
11* K183 058 Gasket
12 K473 016 Spring
13 K012 003 Adapter
14* K41RB72143 O-Ring
* Parts included in seal kit
Normally Closed
Key
1-14" Body
Inch mm
H
9.30 236
J
5.34 136
K
3.44 87
L
.25 6
M
.50 13
N
2.31 59
P
11.14 283
Q
4.56 116
R
11.48 292
Top view indicates flow through 3-Way
valve with coil de-energized.
NOTE: For normal valve operation, override
must be in “out” position.
Service Kits
Includ e all parts normally required for
in-service maintenance:
1-1/4" Basic Valve with standard
service P-Pilot .............K352 078
Exhaust
Pressure
Normally Open
Key 1-1/4" Valve Description
1
1" Tap
K053 111
Body (N.C.)
1-1/4" Tap
K053 112
1-1/2" Tap
K053 113
1A
1" Tap
K053 114
Body (N.O.)
1-1/4" Tap
K053 115
1-1/2" Tap
K053 116
2 K313 029 Upper Piston Assy
3* H137 52 O-Ring
4* H137 28 Seal
Dimensions

Parker "N" Series Specifications

General

Series	N
Category	Plumbing Product
Type	Needle Valve
Material	Brass
Connection Type	NPT
Temperature Rating	-65°F to 250°F
