Page 15
0
10 20 30 40 50 60 70 80 90 100
10
20
30
40
50
60
70
80
90
100
Set-point value(%)
(CMD)
Valve stroke(%)
(POS)
MAX adjustable from 75-100%
MIN adjustable from 0-25%
Figure 14. Graph CUTOFF
