Parker PA Series Installation, Operating, & Maintenance Instructions

Page 19
OUTPUT
Factory setting:
ANALOG option: POS
ANALOG TYPE option: 4-20 mA
This function is used to output an analog signal of the current position (POS) or of the set-point value (CMD). Two output signal
types (4-20 mA, 0-20 mA) can be selected.
Use the arrow keys to scroll to OUTPUT and press the ENT key to open the selection menu. Use the arrow keys to navigate to
a specific function. Use the SEL key to set the desired feature. Press the EXIT key to return to the main menu.
Figure 21. Operating sequence OUTPUT
Figure 22. Operating sequence OUTPUT TYPE
0-20 mA
4-20 mA
SEL
TYPE
ENT
EXIT
OUTPUT
ENT
EXIT
POS
CMD
SEL
TYPE
