Catalog HY13-PMD500-SM/US
PGP/PGM 500 Series
Gear Pumps & Motors Service Manual
Assembly Instructions
Figure 12
Figure 13
10) Install gear housing
(Fig. 12)
.
Be sure to line up witness marks as press down.
11) Assemble new sealing parts in thrust block and
verify orientation
(Fig. 13)
.
