PVSG User Guide
5
Mating connector part numbers
Connector Possible mating part number
J11 connector,
4-pin, code D
3M: 3N104-D000-S08 BF
J12 connector,
5-pin, code B
AMP: 4-2271112-1
e following tables shows the pin-outs for the M12 connectors:
J11 Connector Pinout
Pin I/O Name Function
1
Ethernet_TX+
Ethernet Transmit+
2
Ethernet_RX+
Ethernet Receive+
3
Ethernet_TX-
Ethernet Transmit-
4
Ethernet_RX-
Ethernet Receive-
J12 Connector Pinout
Pin I/O Name Function
1
GND
USB GND
2
PWR
USB PWR
3
D+
USB D+
4
D-
USB D-
5
USB_OTG
USB OTG ID
