Parker Torqmotor TF Series User Manual

HY13-1527-M1/US
Torqmotor™ Service Procedure
TF, TG, TH and TL Series
Parker Hannifin Corporation
Hydraulic Pump/Motor Division
Greeneville, TN 37745 US
15
TG Service Parts List Chart
EXPLODED VIEW SPEED SENSOR
ITEM # 12 12 12A 12B 12C 12D 12E 12F
COUPLING COUPLING 5/8-18 LOCK RETAINING
DESCRIPTION SHAFT SHAFT KEY NUT WASHER BOLT WASHER RING
01- Long 6B Snapwire Groove ME019001 ME019301
02- Long Woodruff, 1/4” Tap Snapwire Groove ME019002 ME019302 038015*
03- 1.25” Straight Keyed 5/8-18 Int. Thd. ME019003 ME019303 039028*** 028413 021482 028992 401333
04- 10B Spline ME019004 ME019304
05- 14 Tooth Spline 5/8-18 Int. Thd. ME019005 ME019305 028413 021482 028992
06- 19 Tooth Spline ME019006
07- 15 Tooth Spline ME019007
08- 1.25” Tapered Shaft ME019000 ME019300 038016**
3
025126
19- 1.38” Tapered 1.125-18 Thd. ME019010 038016**
7
025139
20- 1.38” Straight Key 5/8 Tap ME019011 ME019311 039028 028518 021482 028992 401658
COUPLING SHAFT GROUP
For reverse timed manifold, use ME015001.
1
Service housing ass’y ITEM #18 with part number suffix-A3 includes ITEM #13,
#14 two req’d, #15 and #19.
2
Select the required bolt number in designated “DISPLACEMENT GROUP” under
bolt ITEM #1, 1A, 1B or 1C shown in designated “OPTION GROUP.”
3
1-20 UNEF slotted nut #025113 is required on 1-1/4” tapered shaft if the desig-
nated “OPTION GROUP” is AAAF, AAAN, or AAAU.
4
ITEM #22 is part of plug & o-ring assy’s but can be serviced separately.
5
Service end cover ME016001J1 includes two #032790 o-rings, ITEM 18A on the
exploded ass’y view that can also be serviced separately.
6
End cover assembly item #2 also includes item #21, #22, #24 and if required item
#23. All but item #21 can be serviced separately.
7
ME018001A1 commutator ass’y. is required if the designated “OPTION GROUP” is
AAAM, AAAN, or AAAP.
8
Order (2) #032790 seals for parts when ordering manifold-style porting.
Standard seal kit #SK000092 includes six #032819 seal rings, #032435 commu-
tator seal, #032817 inner seal, #028515 and #029118 back washers, #478035
dirt & water seal, #406018 grease pack, bulletin #050016.
Special seal kit #SK000093 for units that use fire retardant fluids includes six
#032820 seal rings, #032435 commutator seal, #032818 inner seal, #028515
and #029118 back up washers, #478035 dirt & water seal, #406018 grease pack,
bulletin #050016.
High Temp commutator seal AAAJ #032861. High temp seal black in color.
(08) 1-1/4 Shaft Castle Nut 1-20 #025139
(08) 1-1/4 Shaft Castle Nut 1-20 #025113
(19) 1-3/8 Shaft Castle Nut 1-1/8-18 #025139
Shaft nuts are zinc dichromate.
EXPLODED VIEW
ITEM #
2
1, 1A, 1B, 1C 2 3 4 16
6
21 & 22
4,6
22
6
23
6
24
END COMMUTATOR SEAL INNER PLUG & O-RING SPEED
DESCRIPTION BOLT (7) COVER SEAL RING (5) SEAL ASSEMBLY O-RING SPRING (2) VALVE SENSOR
AAAA Black Paint Item #1 ME016000 032435 032819 032817
AAAC Corrosion Resistant Paint Item #1 ME016000 032435 032819 032817
AAAF Castle Nut Replacing Item #1 ME016000 032435 032819 032817
Patch Lock Nut
AAAG Fluorocarbon Seals Item #1 ME016000 032435 032820 032818
AAAT Bidirectional Shuttle Item #1A
6
ME016003A1 032435 032819 032817 036297 032791 401642 415569
Valve Endcover 11:00
AAAU Bidirectional Shuttle Item #1A
6
ME016003A1 032435 032819 032817 036297 032791 401642 415569
Valve Endcover 11:00 & Castle Nut
BBBA 1000 PSI Cross Port Item #1C
6
ME016004A1 032435 032819 032817 411063A1 032424 410009-40, 1000 PSI
Relief Endcover
BBBG 1500 PSI Cross Port Item #1C ME016004A5 032435 032819 032817 411063A1 032424 410009-07, 1500 PSI
Relief Endcover
BBBB 2000 PSI Cross Port Item #1C
6
ME016004A2 032435 032819 032817 411063A1 032424 410009-09, 2000 PSI
Relief Endcover
BBCG 2500 PSI Cross Port Item #1C ME016004A6 032435 032819 032817 411063A1 032424 410009-11, 2500 PSI
Relief Endcover
BBBC 3000 PSI Cross Port Item #1C
6
ME016004A3 032435 032819 032817 411063A1 032424 410009-13, 3000 PSI
Relief Endcover
BBBD 4000 PSI Cross Port Item #1C
6
ME01604A4 032435 032819 032817 411063A1 032424 410009-16, 4000 PSI
Relief Endcover
FSAA Speed Sensor Option Item #1 ME016000 032435 032819 032817 455063
OPTION GROUP
* (1/4 x 1)
** (5/16 x 1)
*** (0.132sq. x 1.437)
