HY13-1527-M1/US
Torqmotor™ Service Procedure
TF, TG, TH and TL Series
Parker Hannifin Corporation
Hydraulic Pump/Motor Division
Greeneville, TN 37745 US
18
EXPLODED VIEW
ITEM # 5 & 6 7 11
1
13
1
14
1
15 17
1
19 20 25
COMMUTATOR MANIFOLD THRUST INNER THRUST THRUST BACKUP OUTER DIRT & WATER BACKUP
DESCRIPTION ASSEMBLY (see note) BEARING BEARING WASHER(2) BEARING WASHER BEARING SEAL WASHER
TL- Service Part # ME018000A1 TL015000 068024 071031 028024 069017 028515 068027 478035 029118
TL Service Parts List Chart
Chart Use Example:
TL0240US080AAAB Torqmotor™ includes part numbers listed to the right of TL (SERIES), 0240 (DISP.), US (MOUNTING/
PORTING), 08 (SHAFT), 0 (ROTATION), and AAAB (OPTION) shown in the left hand column of the chart.
Caution:
The charted component service information is for the Torqmotors listed only. Refer to the original equipment manufacturer of
the equipment using the Torqmotor for assembly numbers not listed below.
EXPLODED VIEW
2
(SELECT ITEM # BOLT PER OPTION GROUP)
ITEM # 1, 1B or 1C 8A 10 9
DISPLACEMENT ROTOR ROTOR DRIVE DRIVE LINK WEAR
(in
3
/rev) BOLT (7) THICKNESS SET LINK “LENGTH” PLATE
0140- 8.6 021271 021387 -------- .6271 TL097003 TL123001 3.414 477014
0195- 12.0 021326 021379 -------- .8768 TL127003 TL123001 3.414 477342
0240- 14.5 021390 021291 021387 1.0643 TL157003 TL153001 3.597 477342
0280- 17.1 021352 021476 021271 1.2518 TL187003 TL183001 3.760 477342
0310- 18.9 021272 -------- -------- 1.3738 TL197003 TL193001 3.887 477342
0360- 22.2 021340 -------- -------- 1.6238 TL237003 TL233001 4.140 477342
EXPLODED VIEW
ITEM #
1
18 2
DESCRIPTION SERVICE REAR
MOUNTING
8
PORTING HOUSING ASS’Y COVER
US- Wheel Mt. (4 Bolt) 7/8” O-Ring TL012000A1 ME016000
LS- Wheel Mt. Front Brake Nose 7/8” O-Ring TL012001A1 ME016000
UB- Wheel Mt. (4 Bolt) 7/8” Rear Radial TL012002A1 ME016002
Mounting Code
Porting Code
EXPLODED VIEW
ITEM # 12 12A 12B 12C 12D 12E 12F
COUPLING 5/8-18 LOCK RETAINING
DESCRIPTION SHAFT KEY NUT WASHER BOLT WASHER RING
08- 1.25” Tapered Shaft TL019000 038016*(5/16 x 1.00)
3
025126 028413 021482 028992 401333
03- 1.25” Str. Keyed 5/8-18 Int. Thd. TL019003
Shaft seal #16, can be replaced without replacing back up ring, #17, or backup washer, #25. Inspect items #17 and #25 to be sure wear or corrosion has not affected
these parts. If not, remove the old shaft seal, noting position and direction of seal lip. To replace the new shaft seal, use only fingers (tools not required) and replace the
seal from the rear of the motor.
If corrosion or wear is a problem and item #17 and #25 must be replaced, the factory recommends replacing the entire housing assembly (TL012xxx0A1).
For reverse timed manifold, use TL015001.
1
Service housing assembly ITEM #18 with part number suffix-A1 includes ITEM #13, #14 , #14, #16, #17, #18, #19, #20 & #25.
2
Select the required bolt number in designated “DISPLACEMENT GROUP” under bolt ITEM #1, 1A, 1B or 1C shown in designated “OPTION GROUP.”
3
1-20 UNEF slotted nut #025113 is required on 1-1/4” tapered shaft if the designated “OPTION GROUP” is AAAF, AAAN, or AAAU.
Standard seal kit #SK000212 includes six #032819 seal rings (buna), #032439 High Temp commutator seal, #032818 inner seal fluorocarbon and #478035 dirt & water
seal, 406018 grease pack and bulletin #050073.
Shaft nuts are zinc dichromate.
EXPLODED VIEW
ITEM #
2
1, 1A, 1B, 1C 2 3 4 16
END COMMUTATOR SEAL INNER
DESCRIPTION BOLT (7) COVER SEAL RING (5) SEAL
AAWM Black Paint Item #1 TL016000 032439 032819 032818
AAWL No Paint Item #1 TL016000 032439 032819 032818
OPTION GROUP
