Parkside PPBS 3 A1 - Safety Functions; Summary

37
GB MT
Summary
A
1 Spark plug connector
2 Starter handle
3 Electric starter
4 Fuel tank
5 Tank cover
6 Fuel pump (primer)
7 Choke lever
8 Screw
9 Air lter cover
10 Cable holder
11 Device cable
12 Star screw
13 Multifunction handle
14 Lower shaft tube
15 Protective cover
16 Locking button
17 Clearing blade
18 Mounting screw
19 Upper shaft tube
20 Eyelet
21 On/Off switch
22 Throttle lock
23 Throttle lever
24 Protective cover
25 Protective cover extension
26 3-tooth blade
27 Spool cap
28 Transport protection
29 Transport protection
30 Maintenance key
31 4 mm hex key
32 5 mm hex key
33 Fuel mixing bottle
34 Battery
35 Charger
36 Double shoulder strap
37 Fastener
38 Body protection
39 Nut
40 Clamping disk
41 Washer
B
42 Screw
43 Shaft mount
44 Screw
C
45 Lock
D
46 Handle mount
47 Receptacle
E
48 Uptake spindle
49 Line cutter
J
50 Click lock
51 Screw
M
52 Click lock
53 Spool
54 Line outlet loop
55 Recess
56 Air lter
57 Air lter housing
58 Spark plug
59 Fuel lter
60 Notch
61 Groove
62 Screw
Safety Functions
22 Throttle lock
Prevents accidental acceleration of the
engine. The throttle can be operated
only when the throttle lock is depressed.
15/24 Protective covers
Protect the operator from accidental
contact with the cutting tool and foreign
bodies being thrown out.Fremdkörpern.
